Schneider ASBCTR212 I/O Module

Product Overview

The ASBCTR212 handles digital input and output operations for Advantys systems. You will find this module in material handling and packaging machines. It reads field sensor states and drives actuators directly. Moreover, this module includes short-circuit protection on every output channel. Therefore, a single fault does not damage the entire unit.

Technical Specifications

The table below lists all key parameters for this I/O module.

Parameter	Value / Description
Full Model	ASBCTR212
Category	I/O Module
Dimensions (W x H x D)	21.2 cm x 9.8 cm x 5.4 cm (8.35 in x 3.86 in x 2.13 in)
Weight	0.41 kg (0.90 lb)
Digital Inputs	8 channels, 24V DC sink type
Digital Outputs	8 channels, 24V DC, 0.5A each
Main Connector	One 20-pin removable terminal block
Onboard Components	24 resistors, 8 optocouplers, 8 transistors, 4 LEDs
Energy Storage	None (no capacitors above 10 µF)
Operating Voltage	24V DC ±20%
Current Draw	0.08 A (logic) + up to 4A (outputs)
Input Delay	< 3 ms typical
Output Switching Speed	1 kHz maximum
Protection	Short-circuit and over-temperature on outputs
Status Indicators	One green power LED, 8 green input LEDs, 8 yellow output LEDs
Mounting	DIN rail (35 mm) with locking foot

The ASBCTR212 stores no significant energy on its PCB. Therefore, you can handle this module immediately after power removal. Use the removable terminal block for all field device wiring. Meanwhile, the optocouplers provide electrical isolation between field and logic.

Installation and Compatibility

You can mount this module on any standard 35 mm DIN rail. Snap the ASBCTR212 onto the rail until the foot locks in place. Then connect the 24V supply to terminals 1 and 2. Always verify output wiring before you enable the channels.

This module communicates via the Advantys backplane bus. It automatically reports its I/O configuration to the master controller. The ASBCTR212 replaces older ASBCTR200 series modules without configuration changes.

Environmental and Safety Data

The ASBCTR212 operates from -10°C to +55°C. It withstands 3g vibration per IEC 60068-2-6 testing. The circuit board has a full conformal coating. Consequently, you can use this module in humid environments. Do not exceed 0.5A per output channel under any condition.
