Schneider AM0984MC0 Modicon Input/Output Module for TSX Micro

The Schneider AM0984MC0 provides mixed I/O capability for Modicon TSX Micro PLCs. You can install this module directly into any standard TSX Micro rack slot. It combines discrete inputs and outputs in a single compact unit. This module suits space-constrained automation applications.

Technical Specifications and Hardware Layout

The Schneider AM0984MC0 measures 100 mm in height. Its width reaches 36 mm, and the depth equals 70 mm. The Schneider AM0984MC0 weighs approximately 0.18 kilograms. A single internal PCB holds all input filtering and output driving circuits. The module provides twelve digital input channels for field sensors. Additionally, it delivers eight transistor output channels for actuator control. The unit stores no energy in capacitors or batteries. One 28-pin front connector handles all field wiring connections.

Input and Output Electrical Ratings

The Schneider AM0984MC0 accepts input voltages from 0 V to 30 V DC. Each input draws a typical current of 7 mA at 24 V DC. The module filters input transitions with a 2 ms hardware delay. For outputs, each transistor channel switches 0.5 A at 24 V DC. The total output current per module reaches 4 A maximum. Consequently, this module drives small solenoids and indicator lamps effectively. Short-circuit protection on outputs prevents damage during wiring faults. Optical isolation separates the field side from the backplane logic.

Installation and Practical Application Tips

You must snap the Schneider AM0984MC0 firmly into a standard TSX Micro rack slot. Transitioning to wiring, use 0.5 mm² to 1.5 mm² stranded copper wire. The screw-type terminals require a 3 mm flathead screwdriver for tightening. Twenty front LEDs show input and output status clearly. The operating temperature range extends from 0°C to 55°C reliably.
