Schneider ALU 131 Pushwheel Switch

Overview

The Schneider ALU 131 Pushwheel Switch provides precise control in industrial automation applications. Its ergonomic design enables smooth operation and reduces operator fatigue. Engineers rely on its sturdy construction and compatibility with RMS-TSG-TZ-C series systems for long-term reliability.

Key Features

Ergonomically designed pushwheel ensures accurate, repeatable input control.
Compact housing allows seamless integration into control panels and machinery.
High-quality materials resist mechanical wear, corrosion, and harsh industrial environments.
Directly compatible with Schneider RMS-TSG-TZ-C series modules for modular automation.

Technical Specifications

Parameter	Details
Manufacturer	Schneider Electric
Model	ALU 131
Series	RMS-TSG-TZ-C
Category	Pushwheel Switch
Switch Type	Mechanical rotary pushwheel
Actuation Force	1.8–2.2 N
Rotation Angle	30° per step
Mounting Type	Panel mount
Dimensions	2.4 x 2.4 x 1.8 in (61 x 61 x 46 mm)
Weight	0.35 lb (0.16 kg)
Contact Material	Silver alloy for low-resistance switching
Electrical Rating	10 A, 250 VAC
Operating Temperature	-20°C to +70°C
Life Cycle	1,000,000 operations
Certifications	CE, UL, RoHS compliant

Applications

The Schneider ALU 131 Pushwheel Switch suits diverse industrial uses:

Manual input for automated machinery and conveyor systems.
Interface for RMS-TSG-TZ-C series PLC and control modules.
Operator panels requiring precise, repeatable rotational input.

Advantages

Improves control accuracy with low friction and smooth actuation.
Enhances durability through corrosion-resistant materials and long operational life.
Simplifies installation with standard panel mount and industry-standard dimensions.
