Schneider 140MMS53502 Motion Control Module for Advanced Automation

Optimized for High-Precision Motion Control with SERCOS Compatibility

The Schneider 140MMS53502 is a sophisticated motion control module from the Modicon Quantum series. This module delivers high-performance capabilities, powered by a 133 MHz processor, and is ideal for demanding automation tasks. It ensures seamless integration with Lexium systems, utilizing SERCOS control output to enhance compatibility and performance.

Key Features of the Schneider 140MMS53502:

• Manufacturer: Schneider Electric
• Product Type: Motion Control Module
• Series: Modicon Quantum
• Model Identifier: 140MMS53502
• Processor Speed: 133 MHz
• Control Output: SERCOS for precision synchronization
• Compatibility: Fully compatible with Lexium systems
• Number of Axes:
  • 8 real axes
  • 4 imaginary axes
  • 4 remote axes
  • 4 coordinate sets
• Functions:
  • Count probe
  • Length measurement
  • Point synchronization
• Mounting Orientation: Vertical
• Housing Material: Durable plastic construction
• Display: Equipped with a display for easy monitoring
• Operating Temperature: 0°C to 40°C
• Storage Temperature: 0°C to 50°C
• Maximum Operating Humidity: 80% RH (non-condensing)
• Maximum Storage Humidity: 80% RH (non-condensing)

Detailed Technical Specifications of Schneider 140MMS53502:

Performance and Functions of the Schneider 140MMS53502:

The 140MMS53502 module is engineered to deliver high-precision motion control. With the ability to control up to 8 real axes, and support for both imaginary and remote axes, this module offers versatile solutions for complex automation systems. It includes up to 4 coordinate sets, facilitating advanced motion synchronization and complex path control.

The module excels in several critical motion control tasks. These include counting probes, length measurements, and point synchronization—essential for precise, high-speed industrial automation processes.

• Processor Power: The 133 MHz processor ensures rapid data processing, enabling real-time motion control.
• SERCOS Control Output: The SERCOS interface provides accurate control over motion systems, ensuring synchronization between devices.
• Integration with Lexium Systems: The module’s compatibility with Lexium systems enhances its integration with other Schneider Electric products, optimizing the overall system performance.

Durability and Environmental Resistance:

The 140MMS53502 is built to endure harsh environments. Its plastic housing provides reliable protection against external factors, while its vertical mounting design optimizes space utilization in control cabinets and enclosures.

• Temperature Range: This module can operate in temperatures from 0°C to 40°C and withstand storage temperatures between 0°C and 50°C.
• Humidity: With an operating and storage humidity rating of 80% RH (non-condensing), it is designed for use in a variety of industrial settings.

Applications of the Schneider 140MMS53502:

• Advanced Motion Control: Ideal for complex motion control tasks that require precision and real-time synchronization.
• Automated Manufacturing Systems: Suitable for controlling multi-axis systems in industrial automation processes.
• Lexium Integration: Perfect for installations using Lexium motors and drives, ensuring seamless system integration.

Why Choose the Schneider 140MMS53502?

• Precision Control: The 140MMS53502 offers advanced motion control, making it perfect for industries that demand high precision.
• Enhanced Compatibility: Its SERCOS interface and compatibility with Lexium systems ensure smooth integration into existing automation setups.
• Durability: Designed with a sturdy plastic housing and resistance to a wide range of environmental conditions, it ensures long-term reliability.
