Schneider 140DVO85300C Discrete Output Module

The 140DVO85300C, part of Schneider Electric’s Modicon Quantum series, is a high-performance discrete output module. It provides 32 output channels using negative logic (sink), offering reliable control in industrial automation.

Key Features of 140DVO85300C

32 Output Channels: Supports simultaneous control of up to 32 devices.
Negative Logic (Sink): Ideal for systems requiring negative logic for output.
Output Voltage Range: Operates between 10 to 30 VDC, ensuring flexibility in different environments.
Short-Circuit and Overvoltage Protection: Protects your system from damage due to faults.
Surge Current Capability: Handles surge currents up to 2.5 A for stable performance under heavy loads.

Technical Specifications for 140DVO85300C

Parameter	Details
Manufacturer	Schneider Electric
Product Type	Discrete Output Module
Product Line	Modicon Quantum
Part Number	140DVO85300C
EAN	3595860032218
Weight	1.00 lbs (0.45 kg)
Output Channels	32
Output Type	Negative logic (sink)
Addressing Requirement	2 output words, 2 input words
Output Voltage	10 to 30 VDC
Short-Circuit Protection	Yes
Surge Current	2.5 A
Overvoltage Protection	Yes
Marking	CE
Format	Standard
Bus Current Requirement	500 mA
Ambient Temperature	0 to 60 °C
Standards	UL 508, CSA
Protective Treatment	Conformal coating

Description

The 140DVO85300C from Schneider Electric is a discrete output module for Modicon Quantum control systems. It offers 32 output channels, providing ample control for automation applications. The module operates with negative logic (sink), making it compatible with a wide variety of industrial devices.

It supports an output voltage range of 10 to 30 VDC, providing the flexibility to adapt to different system requirements. Furthermore, the module comes equipped with short-circuit and overvoltage protection, ensuring the safety of the control system and preventing damage during electrical faults. With a surge current handling capability of 2.5 A, it ensures reliable performance even in high-load situations.

To power the module, it requires a bus current of 500 mA, operating efficiently within an ambient temperature range of 0 to 60 °C. This makes it suitable for use in diverse industrial environments, where temperature conditions can fluctuate.

Compliant with UL 508 and CSA standards, the 140DVO85300C guarantees high safety and quality standards. It is marked with CE, certifying its conformity with European safety regulations. Additionally, the module features a conformal coating to protect it from dust and moisture, making it durable in challenging environments.

Weighing just 0.45 kg, the module’s compact design makes it easy to integrate into existing setups. It is an efficient and reliable solution for your automation needs.
