Schneider 140CRP93200 RIO Head-End Adaptor

Overview

The Schneider 140CRP93200 is a crucial RIO head-end adaptor module designed for the Modicon Quantum automation platform. It plays a vital role in facilitating communication between the central processing unit (CPU) and remote I/O devices. This RIO module offers distributed I/O capabilities, which enhances the flexibility, scalability, and communication speed of industrial automation systems.

Moreover, the 140CRP93200 integrates built-in redundancy to ensure system reliability. In case of primary system failure, this feature guarantees uninterrupted operation, minimizing downtime and enhancing system availability.

Key Features

High-Speed Communication: With a transmission rate of 1544 Mbit/s, this module ensures rapid data exchange between devices in the network.
Distributed I/O: The 140CRP93200 supports 64 input and 64 output I/O words per drop, offering expansive I/O capabilities.
Redundant Connectivity: This module includes redundant cables and female connectors for reliable electrical connections and to prevent potential communication disruptions.
Built-In Isolation: It features 500V DC isolation between coaxial center and ground, protecting the system from electrical surges and ensuring the safety of equipment.
Wide Environmental Range: The 140CRP93200 operates in temperatures ranging from 0°C to 60°C and can be stored in environments between -40°C to 85°C, making it suitable for diverse industrial settings.
Compact Design: Weighing just 0.5 kg, this module is easy to install and supports rack mounting, making it adaptable to various setups.

Technical Specifications

Specification	Details
Model Number	140CRP93200
Manufacturer	Schneider Electric
Product Line	Modicon Quantum
Product Type	RIO Head-End Adaptor Module
Maximum Drops/Network	31 Drops
I/O Words per Drop	64 I/O input & 64 I/O output words
Cable Type	75 Ohm Coaxial Cable
Transmission Rate	1544 Mbit/s
Dynamic Range	35 dB
Isolation Voltage	500 V DC (Coaxial center to ground)
Electrical Connection	2 Female Connectors (Redundant Cable)
Power Dissipation	3 W (2 Channels)
Bus Current Requirement	750 mA (2 Channels)
Operating Temperature Range	0°C to 60°C
Storage Temperature Range	-40°C to 85°C
Relative Humidity	95% Non-Condensing
Operating Altitude	< 5000 m (16,404 ft)
Certifications	FM Class 1 Division 2, UL 508, CSA C22.2 No 142, CUL, IEC 801-2
Dimensions (W x H)	4.1 x 3.0 x 1.2 inches (104 x 76 x 30 mm)
Weight	0.5 kg (1.1 lbs)

Compatibility

Modicon Quantum CPUs and I/O Modules (200/500/800 Series)
Symax I/O Modules (Any Mix)

Applications

The Schneider 140CRP93200 is designed for a wide range of industrial applications, where high-performance and reliability are paramount. These include:

Industrial Automation Systems: Its distributed I/O capabilities enhance flexibility and scalability.
Process Control: Reliable communication ensures continuous operation in critical environments.
Energy Distribution: With redundant features, this module ensures operational stability in energy applications.
Manufacturing: It is ideal for control systems in manufacturing environments, where uptime is critical.

Benefits

High-Speed Data Transmission: With a 1544 Mbit/s transmission rate, this module enables quick and efficient communication across devices.
Enhanced Reliability: Built-in redundant cables and female connectors ensure a fail-safe system, preventing costly downtimes.
Wide Operating Range: It operates effectively in a range of temperatures (0°C to 60°C), which suits various industrial environments.
Compact & Efficient: The lightweight design (just 0.5 kg) facilitates easy installation, saving space and improving efficiency in control panels.

Why Choose the Schneider 140CRP93200?

The Schneider 140CRP93200 is the ideal choice for industrial automation systems where reliability, flexibility, and speed are essential. With its high-speed communication, redundant connections, and wide environmental tolerance, this module ensures smooth operations in even the most challenging conditions. It is an excellent addition to any Modicon Quantum platform, providing reliable communication between CPUs and remote I/O devices.
