ProSoft MVI56E-MCMXT Communication Module

Brand: ProSoft
Model: MVI56E-MCMXT
Category: Modbus Master/Slave Communication Module

Overview

The ProSoft MVI56E-MCMXT is a high-performance Modbus Master/Slave Enhanced Communication Module designed for seamless integration with the Logix-XT™ control platform. This module enables smooth communication between Rockwell Automation ControlLogix processors and devices that utilize the Modbus RTU/ASCII communication protocol. Whether you need to initiate or respond to Modbus requests, the MVI56E-MCMXT ensures efficient, real-time data exchange, making it an ideal solution for various industrial applications.

Key Features

Master/Slave Communication: The module supports both Modbus Master and Modbus Slave modes, offering flexibility for a wide range of communication scenarios.
Modbus Function Support: Supports Modbus functions such as Read/Write Coils, Input Registers, and Holding Registers, ensuring compatibility with various Modbus devices.
Real-Time Data Exchange: Enables efficient and reliable data transmission between ControlLogix processors and Modbus-compatible devices.
Multiple Master Communication: Can handle communication with multiple Modbus Master devices, ideal for complex system setups.
Diagnostic Indicators: Equipped with status and error indicators to simplify troubleshooting and ensure system reliability.

Technical Specifications

Specification	Details
Model	MVI56E-MCMXT
Supported Modbus Functions	1, 2, 3, 4, 5, 6, 8, 15, 16, 17, 22, 23
Modbus Operation Mode	Master/Slave
Data Table Size	Up to 4096 data points
Serial Port Baud Rate	300 to 38,400 bps
Communication Protocol	Modbus RTU/ASCII
Environmental Design	Designed for extreme environments
Operating Temperature	0°C to 60°C (32°F to 140°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Dimensions	Length: 22 cm, Width: 17.3 cm, Height: 5.2 cm
Weight	0.55 kg
