The ICS Triplex TC20502 delivers reliable dual-channel analog output, supporting voltage or current signals for industrial PLC systems. It ensures precision and safety in demanding machine and process control applications, making it ideal for safety-critical systems.
Key Features
The TC20502 integrates robust protections and versatile configuration options for high-reliability automation environments.
- Dual-Channel Output: Supports two independent analog outputs for precise process control.
- Output Modes: Configurable for voltage or current signals, meeting diverse application requirements.
- Programmable Filters: Allows fine-tuning of signal response to reduce noise and improve stability.
- Short-Circuit Protection: Safeguards modules and connected equipment from accidental shorts.
- Overcurrent Protection: Prevents damage due to excessive current draw under fault conditions.
- Ruggedized Design: Built to withstand harsh industrial environments.
- Ease of Installation: DIN rail compatible and simple to configure for rapid deployment.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | TC20502 |
| Output Channels | 2 analog channels |
| Output Type | Voltage or current |
| Output Protection | Short-circuit and overcurrent protection |
| Programmable Filters | Yes, for noise reduction and stability |
| Resolution | 12-bit standard (dependent on PLC configuration) |
| Isolation | 2500 V between analog and digital logic |
| Power Supply | 24 VDC nominal |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | –25°C to +70°C (–13°F to 158°F) |
| Humidity | 10–95% RH, non-condensing |
| Weight | 1.1 kg (2.43 lb) |
| Mounting | DIN rail compatible |
Origin
| Parameter | Specification |
|---|---|
| Country of Manufacture | USA |
Applications
- Provides precise analog control for PLCs in industrial machine and process automation.
- Ideal for safety-critical applications where dual output reliability is essential.
- Voltage or current output suits control loops, valve actuators, and process instrumentation.
- Integrated protections minimize system downtime and prevent hardware damage.
