ProSoft MVI56-MNET Modbus TCP/IP Communication Module

Overview

The ProSoft MVI56-MNET is a Modbus TCP/IP communication module designed to seamlessly integrate ControlLogix processors with devices supporting the Modbus TCP/IP protocol. This powerful module simplifies data exchange, enabling enhanced connectivity across a wide range of industrial applications. Its compatibility and flexibility make it ideal for connecting ControlLogix processors to Modbus TCP/IP networks in industries such as food processing, petrochemical, automobile manufacturing, and more.

Key Features

Efficient Data Transfer: The MVI56-MNET facilitates fast and reliable data exchange between ControlLogix processors and Modbus TCP/IP network devices.
Supports Large Data Loads: It handles up to 5000 registers for data transfer using block transfer or side-connect interface.
Configurable Memory Usage: Users can define the module’s memory usage to optimize performance for specific applications.
Ethernet Compatibility: The module supports 10/100 MB Ethernet, ensuring high-speed and reliable communication.
Customizable Parameters: It features configurable client parameters, including response delay and floating-point support, offering flexibility for diverse uses.

General Specifications

Specification	Details
Form Factor	Single Slot 1756 Chassis
Compatibility	Compatible with ControlLogix processors
Module Type	I/O Module, with direct access to processor memory
Ladder Logic	Used for data transfer between module and processor
Memory Usage	User-definable for customized performance
Data Transfer	Supports 5000 registers using block transfer or side-connect interface

Hardware Specifications

Specification	Details
Operating Temperature	0°C to 60°C (32°F to 140°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Shock Resistance	30g operational, 50g non-operational
Vibration Resistance	5g from 10 to 150 Hz
Relative Humidity	5% to 95% (non-condensing)
LED Indicators	Module status, backplane transfer status, application status, serial activity, Ethernet port

Applications

The MVI56-MNET finds application across multiple industries where fast, reliable communication is crucial, including:

Food Processing: Enables control of production processes and monitoring of systems.
Petrochemical: Connects a wide range of devices for data collection and process control.
Pulp and Paper: Provides seamless communication between ControlLogix systems and Modbus network devices.
Automobile Manufacturing: Optimizes automation systems and enhances production line control.
Water and Wastewater: Ensures reliable data transfer between control systems and field devices for process monitoring.
Oil and Gas: Facilitates robust connectivity for remote operations and process automation.
Power and Electric: Enhances monitoring and control for energy distribution and management systems.

Contact Information

For sales and support, ProSoft Technology offers unlimited technical assistance. Reach out to their worldwide technical support team via phone or email, with contact details provided for various regions and languages spoken.
