ICS Triplex T9851 Termination Assembly

The ICS Triplex T9851 terminates field wiring before signals reach Trusted and Regent I/O modules. System integrators choose this assembly when clean signal routing demands a dedicated junction point. Consequently, the unit simplifies maintenance and reduces wiring errors during commissioning.

Physical Dimensions and Weight Data

Cabinet space often limits how technicians arrange termination hardware inside control racks. Therefore, the ICS Triplex T9851 keeps a slim profile while accommodating full field wiring density. It weighs roughly 0.8 kg and fits a standard 6U rack slot. Additionally, its dimensions measure 233 mm by 160 mm by 40 mm.

Interfaces and Connectivity Features

Reliable signal transfer depends on secure terminations at every field point. The ICS Triplex T9851 provides screw terminals that accept wires up to 2.5 mm². Furthermore, labelled connection points let technicians trace circuits quickly during troubleshooting. The assembly mates directly with companion I/O modules through a dedicated backplane link.

Component Count and Construction Details

Internal construction shapes both durability and long-term contact reliability. The ICS Triplex T9851 carries more than 40 terminal positions within one housing. Moreover, gold-plated contacts resist corrosion in humid plant conditions. The housing material meets flame-retardant standards for industrial panels.

Key Technical Specifications

Parameter	Specification
Assembly Type	Field termination assembly
Dimensions	233 × 160 × 40 mm
Weight	0.8 kg
Rack Size	6U
Terminal Positions	40+ screw terminals
Wire Size	Up to 2.5 mm²
Contact Plating	Gold-plated
Housing Material	Flame-retardant
Operating Temperature	0°C to 60°C
Voltage Rating	300 V
Current Rating	5 A per terminal
Isolation Voltage	500 VDC
Diagnostic Coverage	Over 99%

Connection Performance and Compliance

Stable contact resistance directly influences overall signal accuracy. The ICS Triplex T9851 maintains low resistance across every terminal position. Meanwhile, isolation voltage reaches 500 VDC between adjacent circuits. Labelled points speed up fault tracing during plant shutdowns.

Industrial sites also demand strict safety certifications before deployment. The assembly complies with IEC and UL wiring standards for control systems. In addition, it meets CE requirements for electromagnetic compatibility. These credentials ensure safe integration with Trusted and Regent hardware.
