ICS Triplex T8131 TMR Expander Processor Module

The ICS Triplex T8131 Expander Processor Module strengthens multi-chassis Trusted architectures by linking the Expander Bus with the Expander Chassis backplane. Engineers use the T8131 to extend system capacity while maintaining high-bandwidth IMB communication and robust fault containment. The module supports rapid diagnostics, hot replacement, and automatic recovery strategies, which greatly enhance availability in safety-critical control systems.

Reliable Multi-Chassis Integration

The T8131 operates with full TMR 3-2-0 fault tolerance, and it leverages hardware-implemented HIFT technology to maintain deterministic performance during abnormal conditions. It coordinates data exchange across UTP cabling or fiber interfaces, offering flexible expansion distances while preserving system synchrony. Clear front-panel indicators simplify real-time health monitoring during commissioning and maintenance.

Technical Specifications

Electrical & Communication

Parameter	Specification
Model Number	T8131
Backplane (IMB) Supply	20–32 VDC
Power Dissipation	45 W
Isolation	50 V basic insulation (module to backplane)
Expander Comms Distance	30 m (TC-301 copper) / 10 km (T8314 fiber TX/RX)

Environmental

Parameter	Specification
Operating Temperature	0°C to +60°C (32°F to 140°F)
Storage Temperature	–25°C to +70°C (–13°F to 158°F)
Relative Humidity	10%–95% non-condensing
