ICS T8153C Trusted Communication Interface Adapter

The ICS T8153C is a Trusted Communication Interface Adapter designed to seamlessly integrate with ICS Triplex PLCs. It connects directly to the rear of the Trusted Communication Interface Module within the Trusted Controller Chassis T8100, enabling reliable communication between the system and external devices. This module ensures smooth and secure communication with remote systems, making it ideal for demanding industrial applications.

Key Features:

Direct Interface Connection: Connects to the Trusted Communication Interface Module via a 78+2-way Inverse DIN41612 M-type connector (SK1).
Multiple Communication Protocols: Supports Ethernet, CAN, and RS-485 protocols for flexible and efficient communication.
Versatile Ports: Provides two 10/100BaseT Ethernet connections, four RS422/485 connections, and two RS232 connections (one with full RS232 functionality).
Ruggedized Design: Built to withstand harsh industrial environments, ensuring reliable performance in challenging conditions.
Easy Installation: Simple plug-and-play setup, allowing for quick integration with ICS Triplex PLC systems.

Applications:

The ICS T8153C is ideal for industries requiring secure and stable communication between PLCs and remote devices. It’s often used in:

Industrial Automation: Facilitating seamless data transfer between systems.
Process Control: Ensuring reliable communication for process monitoring and control.
Machine Control: Enabling communication between machine controllers and other devices.

Technical Specifications

Specification	Value
Part Number	T8153C
Manufacturer	ICS Triplex
Product Type	Trusted Communication Interface Adapter
Supported Protocols	Ethernet, CAN, RS-485
Ethernet Ports	2 x 10/100BaseT
RS422/485 Ports	4
RS232 Ports	2 (1 with full RS232 functionality)
Connector Type	78+2-way Inverse DIN41612 M-type (SK1)
Power Supply	24V DC
Operating Temperature	-20°C to +60°C
Storage Temperature	-40°C to +85°C
Weight	0.85 lbs (0.39 kg)
Dimensions	7.5 x 5.2 x 2.0 inches (190.5 x 132.1 x 50.8 mm)
Current Consumption	300 mA at 24V DC

Installation and Integration:

The ICS T8153C offers a straightforward installation process, making it easy to connect with the Trusted Communication Interface Module. Its ruggedized design ensures durability in industrial environments, while the multi-protocol support guarantees compatibility with a wide range of systems. With Ethernet, CAN, and RS-485 connectivity, this module provides flexible and reliable communication for a variety of industrial applications.
