Honeywell DC-PDIS51 Digital Input Module

Core Functionality and System Role

The Honeywell DC-PDIS51 digital input module serves as a key component within the Experion PKS C300 distributed control architecture. This module is part of the I/O system for the C300 controller, providing a direct interface for 24 VDC discrete field devices. Furthermore, it connects seamlessly to the C300 controller’s I/O subsystem to enable reliable process monitoring and logic execution.

Technical Specifications

The following table details the core technical parameters for the Honeywell DC-PDIS51:

Parameter	Specification
Model Number	DC-PDIS51
Product Type	Digital Input IOM (I/O Module)
System Compatibility	Experion PKS C300 Controller, Series C I/O
Input Channels	24 points (differential), 2 groups of 12 channels
Nominal Input Voltage	24 VDC
Input Voltage Range	18 to 30 VDC
ON Threshold	≥ 10 VDC (2 mA minimum)
OFF Threshold	≤ 5 VDC (0.7 mA minimum)
Input Current	8 mA per channel at 24VDC
Input Impedance	3.4 kΩ
Filter Response Time	0.5 ms
Isolation	Galvanic, 1000 VDC
Power Dissipation	4.5 W maximum
Current Draw	165 mA maximum at 5 VDC, 250 mA maximum at 24 VDC
Dimensions (H × W × D)	17.3 × 4.5 × 15.0 cm (6.8 × 1.8 × 5.9 in)
Weight	0.73 kg (1.6 lbs)
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 85°C
Agency Approvals	UL, cUL, CE, FM, CSA

Design and Integration Features

The Honeywell DC-PDIS51 features a compact, modular design that simplifies installation in Series C I/O racks. Its high-density 24-channel configuration maximizes I/O capacity within limited cabinet space. LED status indicators on the front panel provide immediate visual confirmation of each channel’s condition. The module also supports hot-swap capability for minimal downtime. Furthermore, you can use it in both non-redundant and redundant configurations (with appropriate IOTA) to meet critical application requirements.

System Compatibility

The Honeywell DC-PDIS51 integrates with Honeywell C300 controllers and Experion PKS release R200 or later. It interfaces with the FTE and IOLINK for fast, deterministic data exchange. Consequently, users can deploy this module for control, monitoring, and ESD (Emergency Shut Down) applications. Finally, its modular design also facilitates easy future upgrades without major system rework.
