Honeywell CC-TDOR11 Digital Output Relay Module

The Honeywell CC-TDOR11 Digital Output Relay Module offers a reliable interface for controlling discrete field devices like solenoids, relays, and indicator lights. It supports redundancy, ensuring high availability in critical industrial control systems. The module is engineered for harsh environments, delivering consistent performance under demanding conditions.

Key Features of the Honeywell CC-TDOR11 Module

32 output channels allow you to control multiple devices at once.
The module uses 24 VDC with a transistor open-collector design for efficient operation.
Redundancy ensures continuous operation, even if one component fails.
Built-in diagnostics help you maintain and troubleshoot the system with ease.
You can configure its safe-state behavior, offering options such as HOLD LAST STATE or SHED TO SAFE STATE.
The module features non-incendive output, making it safe for hazardous areas.
Its robust design ensures durability, even in harsh industrial settings.

Applications of the Honeywell CC-TDOR11

Industrial Control Systems: The module is ideal for controlling field devices in automated control systems.
Process Automation: It provides reliable relay control for process systems requiring high availability.
Safety and Diagnostics: It supports safety protocols and offers diagnostic features to detect issues early.
Hazardous Areas: Its non-incendive output makes it suitable for environments where explosion risk is a concern.

Technical Specifications

Specification	Value
Model	CC-TDOR11
Output Type	24 VDC, transistor open-collector
Number of Channels	32
Maximum Current per Channel	500 mA (continuous), 1 A (1 second)
Maximum Power Dissipation per Channel	1.8 W at 24 VDC, 500 mA
Channel-to-Channel Isolation	500 Vrms for 60 seconds
Common-to-Channel Isolation	500 Vrms for 60 seconds
Open-circuit Detection	Yes, per channel
Output Rise Time	< 1 ms
Output Fall Time	< 1 ms
Operating Temperature Range	-40°C to +70°C
Storage Temperature Range	-40°C to +85°C
Relative Humidity	0% to 95%, non-condensing
Vibration Resistance	5 to 500 Hz, 0.03 inches double amplitude
Shock Resistance	10 g, 11 ms, half-sine wave

Dimensions and Weight

Dimensions: Compact size fits into tight spaces.
Weight: Lightweight for easy installation.

The Honeywell CC-TDOR11 module is built to handle demanding industrial tasks. With its robust features and high current capacity, it ensures reliable operation in automation systems and critical control processes.
