Honeywell 900H03-0001 Digital Output Module

The Honeywell 900H03-0001 is a high-performance digital output module designed for seamless integration within the HC900 control system. This module effectively interfaces with a variety of output devices, such as actuators, valves, and solenoids, providing reliable and accurate signal processing for industrial automation applications.

Key Features:

Input Voltage Range: 420–240 VAC, ensuring compatibility with a wide range of input sources.
Output Voltage Range: 120–242 VAC, suitable for driving different types of industrial output devices.
Output Current: Provides 8A per channel, ensuring sufficient current supply for high-demand applications.
Number of Channels: Features 8 channels for simultaneous control of multiple devices.
Output Type: Utilizes Triac solid-state outputs for efficient, reliable switching.
Mounting: Designed for easy integration with DIN rail systems, streamlining installation.
Shorting Comb: Simplifies connections to a common voltage source, reducing wiring complexity.
Protection: Equipped with MOV (Metal Oxide Varistor) for transient over-voltage protection, enhancing system safety.
Field-Replacement Fuses: Allows for easy replacement of fuses in the field, minimizing downtime.
State Indicator: Each channel is equipped with a green LED indicator, providing clear status information.

Technical Specifications:

Parameter	Specification
Model Number	900H03-0001
Input Voltage	420–240 VAC
Output Voltage	120–242 VAC
Output Current	8A per channel
Number of Channels	8
Output Type	Triac solid-state outputs
Mounting	DIN rail
Shorting Comb	Simplifies connections to common voltage source
Protection	MOV for transient over-voltage protection
Field-Replacement Fuses	Easy replacement in the field
State Indicator	Green LED per channel
Dimensions	14.43 cm (H) x 19.05 cm (W) x 7.0 cm (D)
Weight	0.34 kg

Description:

The Honeywell 900H03-0001 digital output module is a robust and reliable solution for controlling a variety of industrial devices. It supports 8 output channels and delivers 8A per channel, making it ideal for heavy-duty applications such as actuator control, valve management, and solenoid operation.

With a wide input voltage range of 420–240 VAC and an output voltage range of 120–242 VAC, this module offers versatility for different industrial automation setups. The Triac solid-state outputs ensure high reliability and quick response times, while the MOV protection safeguards the module against harmful voltage surges.

Its DIN rail mounting system ensures easy installation, while the green LED state indicators provide instant feedback on operational status. Additionally, the field-replaceable fuses simplify maintenance and minimize system downtime.
