Honeywell 8U-PAIH54 High-Level Analog Input Module

The Honeywell 8U-PAIH54 is a high-performance analog input module designed for use within the Honeywell Series 8 I/O Terminal Assembly (IOTA). This module efficiently handles a range of input signals, making it ideal for various industrial automation applications. With robust features like high-resolution input and accurate signal conversion, the 8U-PAIH54 ensures reliable performance in demanding environments.

Key Features:

Model: 8U-PAIH54
Manufacturer: Honeywell
Product Type: High-Level Analog Input Module
Input Signal Types: Differential and Single-ended
Input Range: 0-10 V, 4-20 mA
Resolution: 16 bits
Accuracy: ±0.1% of full scale
Operating Voltage: 24 VDC
Operating Temperature Range: -40°C to +85°C
Dimensions: 100 mm x 68 mm x 50 mm (3.9 in x 2.7 in x 2.0 in)
Weight: 0.5 kg (1.1 lbs)

Technical Specifications:

Parameter	Value
Manufacturer	Honeywell
Model Number	8U-PAIH54
Product Type	High-Level Analog Input Module
Input Signal Types	Differential, Single-ended
Input Range	0-10 V, 4-20 mA
Resolution	16 bits
Accuracy	±0.1% of full scale
Operating Voltage	24 VDC
Operating Temperature	-40°C to +85°C
Dimensions	100 mm x 68 mm x 50 mm
Weight	0.5 kg (1.1 lbs)

Description:

The Honeywell 8U-PAIH54 analog input module is specifically designed to work seamlessly within the Honeywell Series 8 I/O Terminal Assembly (IOTA). It supports both differential and single-ended input signals, providing flexibility for various industrial control systems. The module offers a high-resolution of 16 bits and an accuracy of ±0.1% of full scale, making it ideal for applications that require precise signal measurement.

This module operates at a 24 VDC voltage and performs reliably within a wide temperature range of -40°C to +85°C, ensuring optimal performance even in extreme conditions. The compact dimensions of 100 mm x 68 mm x 50 mm and a weight of just 0.5 kg make it easy to integrate into existing control systems, while its efficient design ensures minimal space usage.
