Honeywell 8C-TDIL61 51306967-175 Analog Input Module

Overview

The Honeywell 8C-TDIL61 51306967-175 is an advanced analog input (AI) module designed for use with the Honeywell Experion PKS distributed control system (DCS). It provides reliable and precise measurement for a wide range of analog signals, including temperature, pressure, flow, and voltage. This module is engineered for applications requiring high accuracy and robust performance in demanding industrial environments.

Key Features

High Accuracy and Repeatability: The 8C-TDIL61 guarantees precise signal conversion with an accuracy of ±0.25% of full scale, ensuring reliable data for critical applications.
Signal Isolation: Offers 2500 V isolation, protecting sensitive equipment from damage caused by voltage spikes or faults.
Wide Input Range: Supports a variety of input types, including voltage (0-10 V), current (4-20 mA), and frequency (4-20 kHz), offering flexibility for different industrial sensors.
Multiple Communication Protocols: Compatible with industry-standard protocols such as HART, Modbus, and Ethernet, ensuring seamless integration with existing systems.
Customizable Configurations: The module provides a range of configuration options, allowing customization to meet specific application requirements.
Compact and Rugged Design: Its compact size ensures easy installation in tight spaces, while the robust design ensures reliable operation in harsh environments.
Conformal Coating: The module is equipped with a conformal coating, offering protection against environmental factors such as humidity and dust.

Technical Specifications

Parameter	Specification
Model Number	8C-TDIL61
Part Number	51306967-175
Input Type	Voltage, Current, Frequency
Input Range	0 to 10 V, 4 to 20 mA, 4 to 20 kHz
Accuracy	±0.25% of full scale
Resolution	12 bits
Isolation	2500 V
Operating Temperature	-40°C to +85°C
Storage Temperature	-40°C to +105°C
Humidity Range	5% to 95% RH, non-condensing
Vibration	5 g peak-to-peak, 10 to 2000 Hz
Shock	50 g, 11 ms

Applications

The Honeywell 8C-TDIL61 51306967-175 is widely used across various industries for monitoring and controlling key parameters. Its versatility makes it suitable for the following applications:

Process Control: This module is commonly deployed in process control applications to monitor critical parameters like temperature, pressure, and flow in industries such as chemicals, pharmaceuticals, and energy.
Machine Control: The 8C-TDIL61 is ideal for machine control applications, where it is used to monitor and control the performance of machinery, including pumps, compressors, and conveyors.
Building Automation: The module is also used in building automation systems, enabling precise control over HVAC systems, lighting, security, and other critical infrastructure components.

Why Choose the Honeywell 8C-TDIL61 51306967-175?

The Honeywell 8C-TDIL61 51306967-175 offers exceptional precision, flexibility, and ruggedness. Its broad input range, high isolation, and support for multiple communication protocols make it a versatile choice for a variety of industrial control applications. With easy installation, maintenance, and customizable configuration options, it is ideal for both process control and machine control environments. Additionally, its conformal coating ensures reliability even in harsh industrial settings.
