Honeywell 51305508-200 Signal Processing Module Specs

The 51305508-200 innovative module from Honeywell handles signal processing tasks inside process control chassis. This unit combines routing circuitry with conditioning stages for stable data flow. Engineers select this module when they need dependable signal handling and quick card cage installation.

Technical Specifications

Parameter	Specification
Product Model	51305508-200
Module Type	Signal Processing Module
Function	Signal routing and conditioning
Interface	Backplane connector, board-to-board contacts
Mounting	Card cage slot
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 85°C
Weight	Approx. 0.29 kg
Dimensions	Approx. 168 mm × 102 mm × 24 mm
Energy Storage	On-board capacitors for local power filtering
Component Count	Conditioning ICs and passive components

Interface and Signal Details

The 51305508-200 connects to the host chassis through a backplane connector and board-to-board contacts. The conditioning stages clean incoming signals before they travel across the backplane. Therefore, technicians gain stable continuity even with dense routing layouts. The module slides into a card cage slot and secures with standard fasteners.

Physical and Environmental Parameters

The module measures roughly 168 mm by 102 mm by 24 mm and weighs about 0.29 kg. Its thin profile fits dense card cages and simplifies panel layout. Meanwhile, the 0°C to 60°C operating range covers typical control room conditions. The on-board capacitors filter local power and absorb transient spikes.

Why This Module Matters

Plant teams value the 51305508-200 for its clean signal path and easy replacement. The conditioning circuits keep levels steady across busy backplane routing. As a result, data errors decline and equipment uptime improves noticeably. Technicians also appreciate the clear silkscreen markings and simple mounting scheme.
