Honeywell 51304754-150 Analog Input Module

The Honeywell 51304754-150 is a high-performance analog input module designed to provide accurate and reliable signal processing in industrial automation applications. This module offers 16 differential input channels, making it ideal for systems that require precise voltage and current measurements. The module integrates seamlessly with Honeywell control systems, delivering enhanced functionality and performance for complex industrial processes.

Technical Specifications

Parameter	Specification
Input Type	Voltage, Current (2-wire or self-powered transmitters)
Input Channels	16 differential input channels
Common Mode Rejection Ratio (dc to 60Hz)	70 dB
Common Mode Voltage (dc to 60Hz)	-6V to +5V peak
A/D Converter Resolution	16 bits (14 bits used)
Input Range	0 to 5V, 1 to 5V, 0.4 to 2V, 4-20mA (through 250Ω)
Normal Mode Rejection Ratio (at 60Hz)	32 dB
Normal Mode Filter Response	Single-pole RC, -3 dB @ 1 Hz
Maximum Normal Mode Input (differential inputs)	±30V
Crosstalk (dc to 60Hz, channel-to-channel)	60 dB
Input Impedance (Voltage Inputs)	>10 MΩ
Maximum Input Voltage (any input referenced to common, no damage)	±30V
Input Scan Rate	4 samples per second per channel
Hardware Accuracy (@ CMV=0 V)	±0.075% full-scale (23.5°C ±2°C)
Transmitter Power Conditioning	Class 1, Div 2 interfacing, 30mA max, 23V min
Surge Withstand Capability (Common Mode)	ANSI/IEEE C37.90.1-1978

Key Features

High-Precision Signal Processing: The Honeywell 51304754-150 ensures accurate voltage and current readings across a wide range of input conditions, offering 16-bit resolution for precise measurements.
Enhanced Rejection Ratios: With 70 dB common mode rejection and 32 dB normal mode rejection, this module ensures excellent noise filtering, ensuring stable and reliable data in industrial environments.
Wide Input Range: The module supports various input ranges such as 0 to 5V, 1 to 5V, 0.4 to 2V, and 4-20mA, offering flexibility for diverse applications.
Fast Response Time: It features a 4 samples per second scan rate for real-time control and data acquisition, optimizing performance in time-sensitive applications.
Robust Diagnostics: The Honeywell 51304754-150 includes various diagnostic features, such as input range checking, broken wire detection, and transmitter power conditioning, ensuring continuous system reliability.

Applications

Process Automation: Ideal for applications that require accurate and fast processing of voltage and current signals in industrial control systems.
Speed and Position Control: The module excels in controlling motors, sensors, and actuators by delivering precise measurements.
Data Acquisition: Its high-resolution input channels are perfect for gathering data from field devices, enabling detailed monitoring and analysis.
Industrial Equipment Monitoring: With its ability to handle high-voltage and current signals, the Honeywell 51304754-150 is perfect for monitoring and controlling industrial equipment performance.
