Honeywell 10315/1/1 I/O Backplane

The 10315/1/1 I/O backplane from Honeywell provides the internal connection path for cards inside industrial burner and safety control cabinets. Plant engineers install this backplane whenever a rack needs reliable power and signal distribution. Consequently, it keeps every installed module communicating without extra wiring between slots.

Key Technical Specifications

The table below outlines the main physical and electrical parameters of the 10315/1/1 backplane.

Parameter	Specification
Product Type	I/O Backplane
Compatibility	Honeywell burner and safety control systems
Dimensions	Approximately 300 mm x 150 mm x 30 mm
Weight	Approximately 0.8 kg (1.8 lbs)
Mounting	Cabinet frame or card cage base
Interface	Backplane bus with multiple card slots
Connectors	Multiple edge connectors and power terminals
Component Count	Backplane traces, slot guides, and mounting hardware
Energy Storage	Filter capacitors for rail stabilization
Slot Count	Multiple module connection positions
Operating Temperature	0 degrees C to 60 degrees C
Storage Temperature	-40 degrees C to 85 degrees C
Humidity	5% to 95% non-condensing

Functional Overview

This backplane routes power and data signals between every card seated in the rack. Therefore, it eliminates point-to-point wiring inside the cabinet. The 10315/1/1 also provides mechanical guides that keep each module firmly aligned. Meanwhile, its onboard energy storage smooths rail voltage during switching transients.

Installation and Handling Notes

Always verify slot assignments before mounting the 10315/1/1 inside a cabinet. In addition, check that the power supply occupies the correct position. Tighten all mounting screws evenly to prevent chassis flex. Finally, confirm grounding continuity before installing any cards.
