GE QPI-21100-C2P | QuickPanel HMI

This QuickPanel HMI provides a color touchscreen interface for machine operators. It connects to PLCs and drives for real-time process monitoring. The unit displays production data and accepts operator commands through its touch surface.

Technical specifications

Parameter	Specification
Brand	GE Fanuc
Model	GE QPI-21100-C2P
Product Family	QuickPanel
Category	HMI (Human-Machine Interface)
Display Size	10.4 inches diagonal
Display Type	Color TFT LCD
Display Resolution	640 x 480 pixels (VGA)
Display Colors	256 colors
Touchscreen Type	Resistive analog touch
Backlight Type	CCFL (cold cathode fluorescent)
Backlight Life	50,000 hours typical
Communication Ports	2 x RS-232, 1 x RS-422/485, 1 x Ethernet (optional)
Memory	4 MB flash (application storage)
Power Supply	24V DC external
Current Consumption	500 mA typical
Number of Components	1 display panel, 1 touch overlay, 1 main PCB, 1 backlight inverter
Dimensions (L x W x D)	Approx. 30 cm x 23 cm x 5 cm
Weight	Approx. 2.5 kg
Energy Storage	1 x lithium battery (clock backup)
Battery Type	CR2032 coin cell
Battery Life	Approximately 5 years
Operating Temperature	0°C to 50°C
Protection Rating	IP65 (front panel only)

Detailed Technical Analysis

This QuickPanel HMI features a 10.4-inch color TFT display with VGA resolution. The screen shows 256 simultaneous colors for clear graphical interfaces. A resistive touch overlay registers operator inputs accurately even with gloves. The CCFL backlight provides 50,000 hours of continuous operation.

Now let us examine its connectivity options. The GE QPI-21100-C2P includes two RS-232 ports and one RS-422/485 port. An optional Ethernet port allows network connectivity for data logging. These ports connect to PLCs from GE, Allen-Bradley, Siemens, and Modbus devices. The unit stores application screens in 4 MB of flash memory.

The front panel meets IP65 protection standards for washdown environments. You can mount this HMI in food processing or chemical plants safely. The GE QPI-21100-C2P weighs 2.5 kilograms and measures 30 by 23 centimeters. A CR2032 lithium battery preserves the real-time clock and configuration data.

Installation and Setup Guidelines

You cut a panel opening of specific dimensions for flush mounting. Use the provided mounting clamps to secure the unit in place. Connect a 24V DC power supply to the terminal block on the rear. The GE QPI-21100-C2P draws approximately 500 milliamps during normal use.

For communication wiring, use shielded cables to reduce electrical noise. Configure the serial port settings to match your target PLC. The QuickPanel software runs on Windows for application development. Download your project through the serial or Ethernet connection.

Practical Applications

Engineers use this HMI for machine monitoring and data entry tasks. For example, you can display production counts and alarm messages on screen. The GE QPI-21100-C2P also allows operators to adjust machine parameters. Its rugged front panel withstands daily cleaning and chemical exposure.

Summary

To conclude, this QuickPanel HMI offers a 10.4-inch color touchscreen interface. It weighs 2.5 kilograms and includes multiple communication ports. Choose GE QPI-21100-C2P for reliable operator interface in harsh industrial environments.
