GE IS200JPDMG1ACC Power Distribution Card for Mark VI

The GE IS200JPDMG1ACC is a high-performance Power Distribution Card, engineered for the Mark VI Turbine Control System. It delivers stable control power to I/O packs, ensuring reliable industrial operation. With integrated short circuit and fuse protection, this card excels in hazardous environments.

Key Features

Provides efficient distribution of protected control power for turbine systems.
Incorporates robust fuse protection on all outputs to prevent damage.
Includes built-in short circuit protection rated up to 20 A.
Supports DIN-rail and panel mounting for versatile installation.
Certified for Class 1 Division 2 and ATEX hazardous locations.
Operates over a wide temperature range from -40°C to +70°C (-40°F to +158°F).

Technical Specifications

Specification	Details
Model Number	IS200JPDMG1ACC
Type	Power Distribution Card
Power Source	125V DC battery system; supports 120/240V AC via converter
Input Voltage	28V DC
Maximum Current	35 Amps
Connectors	J1 and J1X connectors for daisy-chaining multiple boards
Wiring	Terminal block for secure connections
Components	24 varistors, 24 two-position plugs arranged in three rows of eight
Short Circuit Protection	Up to 20A, suitable for gas turbines with separate ignition transformers
Mounting Strategy	DIN-rail or panel mounting
Operating Temperature	-40°C to +70°C (-40°F to +158°F)
Certifications	UL/ATEX HazLoc, Class 1 Division 2, ATEX zones
Protection Features	Fuse protection for all outputs
