GE IS200ISRJG1A IS200ISRJG1AAA Rack Power Supply Board

The IS200ISRJG1A IS200ISRJG1AAA functions as a rack power supply board for turbine systems. This printed circuit board belongs to the Mark VI Speedtronic series from General Electric. The IS200ISRJG1A serves as the standard version for rack power distribution. Its variant, the IS200ISRJG1AAA, includes a conformal coating for enhanced circuit protection. Both boards supply regulated power to VME rack modules for steam and gas turbine controls.

Core Technical Specifications

This board provides multiple DC voltage outputs for rack module operation. You will also find built-in overvoltage protection on each output channel. The board stores minimal energy but uses capacitors for voltage regulation. Meanwhile, the backplane connector distributes power to all rack slots.

Parameter	Specification
Full Model No.	IS200ISRJG1A IS200ISRJG1AAA
Manufacturer	GE Industrial Systems (General Electric)
Series	Mark VI Speedtronic
Board Category	Rack Power Supply Board
Weight	Approximately 0.48 kg
Dimensions (H x W x D)	6.0 cm x 17.5 cm x 4.0 cm
DC Output Channels	5 output channels (3.3V, 5V, ±12V, 24V)
Output Current	3A to 8A per channel depending on voltage
Overvoltage Protection	Built-in crowbar circuits per output
Input Voltage	100 to 240 VAC or 125 VDC
Backplane Interface	VME64 compatible
Energy Storage	Capacitors for voltage smoothing and hold-up
Coating (for AAA)	Conformal coated against moisture and dust

Installation and System Integration

Install the IS200ISRJG1A IS200ISRJG1AAA into the designated power supply slot. The board connects directly to the rack backplane for power distribution. Meanwhile, the front panel provides status LEDs for monitoring. Therefore, proper insertion ensures reliable power to all rack modules.
