GE IC697CPX782 CPU Module

The GE IC697CPX782 is a powerful CPU module designed specifically for GE Fanuc Series 90-70 PLCs. With its 80486DX4 microprocessor, this module offers reliable and high-speed processing for demanding industrial automation tasks.

Key Features and Specifications

Model Number: IC697CPX782
Manufacturer: GE Fanuc Emerson
Product Line: Series 90-70 PLCs
Product Type: CPU Module
Part Number: IC697CPX782
Category: Industrial Automation, PLC Modules

Technical Specifications

Specification	Details
Microprocessor	80486DX4
Clock Speed	96 MHz
RAM	1 MB
Non-volatile RAM (NV-RAM)	256 KB
Voltage Input	5 Volts DC
Serial Ports	3 (RS-232 and RS-485)
Maximum I/O Support	8000 Analog I/O
	12,000 Mixed I/O
Nominal Current	3.1 Amps at 5V
Battery Life	5 years at 20°C
Operating Temperature	0°C to 60°C
Weight	2.00 lbs (0.91 kg)

Detailed Description

The GE IC697CPX782 CPU module drives the Series 90-70 PLCs, providing superior processing power. It uses the 80486DX4 microprocessor, which operates at 96 MHz, ensuring reliable, high-speed performance. This module’s design allows it to handle complex automation tasks and control systems with ease.

Incorporating 1 MB of RAM and 256 KB of NV-RAM, the module guarantees fast data processing and secure memory retention. It supports up to 8000 analog I/O and 12,000 mixed I/O signals, making it a versatile choice for a wide range of industrial applications.

Flexible Connectivity Options

Ethernet and Serial Ports: You can easily connect a programmer via Ethernet by installing an Ethernet interface module in the PLC. Alternatively, use the three on-board serial ports to connect:
- Port 1: Supports RS-232 communication.
- Ports 2 and 3: Support RS-485 communication.
  The LED indicators on the front panel provide clear feedback on the status of these connections, simplifying the monitoring process.
Firmware Upgrades: Perform in-system firmware upgrades to keep the module current with the latest updates, ensuring that it continues to meet your operational needs.

Power Requirements and Operating Conditions

The IC697CPX782 operates on 5V DC with a nominal current requirement of 3.1 Amps. It functions optimally within a temperature range of 0°C to 60°C, making it well-suited for use in industrial environments where conditions can vary.

Applications

The GE IC697CPX782 CPU module is perfect for:

Industrial Automation: It powers Series 90-70 PLCs, making it ideal for factory automation and process control.
Machine Monitoring: The module supports real-time diagnostics, ensuring that critical machinery operates efficiently.
Process Control: Ideal for managing complex systems, from chemical plants to energy facilities.
Building Automation: It helps control HVAC systems, lighting, and security infrastructure, streamlining building management.
