GE IC694MDL754 32-Point Output Module for RX3i PACSystems

Overview

The GE IC694MDL754 is a high-density discrete output module specifically designed for the RX3i PACSystem. This module includes 32 output points divided into two isolated groups of 16. Each group can handle 12/24 VDC, delivering a 0.75 Amp current per point. The IC694MDL754 provides essential protection features, including short-circuit, overcurrent, and overtemperature safeguards, ensuring safe and reliable operation.

Technical Specifications

Specification	Details
Manufacturer	GE Fanuc Emerson
Product Line	RX3i PACSystem
Part Number	IC694MDL754
Output Channels	32 (2 groups of 16 channels each)
Operating Voltage	12/24 VDC
Output Voltage Range	10.2 – 30.0 VDC
Output Current per Channel	0.75 Amps
Switching Current	0.75 Amps per point
Response Time (Max)	0.5 ms
Wiring Configuration	Positive Logic
Point-to-Point Isolation	Yes (250 VAC continuous, 1500 VAC for 1 minute)
Protection	Short-circuit, overcurrent, overtemperature (auto recovery)
Inrush Current Rating	3.0 Amps (for 10 ms)
Current Draw (Max)	300 mA (from 5V backplane)
LED Indicators	32 LEDs (1 per output)
Terminal Block Compatibility	Box-style (IC694TBB032) / Spring-style (IC694TBS032)
Dimensions	4.5 x 3.5 x 1.0 in (114 x 89 x 25 mm)
Weight	0.88 lbs (0.40 kg)
Environmental Rating	Standard (Not rated for harsh environments)
Product Lifecycle	Active

Key Features

32 Discrete Output Channels: The IC694MDL754 provides 32 output points, organized into two groups of 16 channels each. It ensures flexibility in controlling external devices with 0.75 Amps output current per channel.
Advanced Protection: The module includes short-circuit, overcurrent, and overtemperature protection. These protections work together to prevent damage and ensure stable operation. If any fault occurs, the module automatically recovers.
Fast Response Time: The IC694MDL754 responds quickly with a maximum response time of 0.5 ms, which is critical in time-sensitive industrial processes.
Wide Voltage Range: The module operates within a voltage range of 10.2 to 30.0 VDC and supports a nominal operating voltage of 12/24 VDC, offering adaptability for different devices and applications.
LED Status Indicators: The IC694MDL754 is equipped with 32 individual LED indicators to display the status of each output channel. This helps operators monitor performance and detect issues promptly.
Easy Integration: This module integrates easily into the RX3i PACSystem. Simply install it into any available slot in the RX3i CPU rack, making it an ideal choice for expanding your system.

Applications

The GE IC694MDL754 is designed for demanding industrial control systems, particularly in applications requiring reliable digital output control. Typical use cases include motor control, manufacturing automation, and process control systems. The module’s compact design and fast response make it a strong choice for high-performance environments.

Compatibility

RX3i Series: The IC694MDL754 is compatible with RX3i PACSystems PLCs. It requires firmware version 2.90 or later.
Terminal Block Options: Use Box-style (IC694TBB032) or Spring-style (IC694TBS032) terminal blocks for easy wiring.

Conclusion

The GE IC694MDL754 is a reliable, high-performance 32-point discrete output module for the RX3i PACSystem. Its robust protection features, quick response time, and wide voltage range make it an excellent choice for various industrial automation tasks. With 32 outputs, it ensures precise control, while the LED indicators allow for real-time monitoring. Whether you are expanding or upgrading your system, this module delivers the performance and reliability your applications require.
