GE IC693UDR005FP1 Series 90-30 PLC

The IC693UDR005FP1 from GE Fanuc functions as a Series 90-30 programmable logic controller with integrated I/O. It combines processor, power supply, and discrete I/O in a single compact unit. This controller delivers reliable automation for small to medium-scale industrial applications. Engineers depend on its all-in-one design for simplified system implementation.

Technical Specifications & Hardware Details

Specification	Detail
Manufacturer	GE Fanuc
Model Number	IC693UDR005FP1
Category	Programmable Logic Controller
Power Supply	100-240 VAC, 50/60 Hz
Discrete Inputs	16 points, 24 VDC sink/source
Discrete Outputs	11 relay outputs
Additional Outputs	5 points, 24 VDC sourcing
Weight	Approximately 1.6 kg (3.53 lbs)
Dimensions (H x W x D)	5.2 in x 5.6 in x 4.5 in (132 mm x 142 mm x 114 mm)
Interface	Integral screw terminals for I/O, programming port
Component Count	Single-unit assembly with processor, power supply, and I/O circuits
Energy Storage	Lithium battery for program and data retention

Integrated I/O Configuration and Field Wiring

The IC693UDR005FP1 provides 16 discrete inputs for sensor and switch connections. It accepts 24 VDC signals from pushbuttons, limit switches, and proximity sensors. This controller delivers 11 relay outputs for actuating solenoids, contactors, and pilot lights. Additionally, it includes 5 solid-state 24 VDC sourcing outputs for indicator applications. You can connect field wiring directly to the integral screw terminals for simplified installation.

Power Supply and System Integration

The unit incorporates a universal power supply that accepts 100-240 VAC input. This flexibility allows global deployment without additional power conditioning equipment. The IC693UDR005FP1 includes a programming port for straightforward configuration and monitoring. You can expand this controller with additional Series 90-30 modules using expansion racks. The onboard lithium battery maintains programs and data during power interruptions.

Processing Capabilities and Application Use

This programmable logic controller executes relay ladder logic for machine and process control. It supports timing, counting, and arithmetic functions for diverse automation tasks. The IC693UDR005FP1 works alongside operator interfaces and sensors for complete system functionality. For similar industrial applications, static trip units and protective relays use comparable control principles. However, this controller specifically addresses compact automation requirements within the GE Series 90-30 ecosystem. Facilities rely on it for conveyors, packaging machines, and material handling equipment.
