GE IC693MDL730E Output Module for Series 90-30 PLC Systems

The GE IC693MDL730E drives AC actuators directly from Series 90-30 PLC outputs. You can install this module into any standard 90-30 rack slot. It provides twelve triac output channels for 120 V AC or 240 V AC loads. This unit suits solenoid valves, motor starters, and heating elements.

Technical Specifications and Hardware Layout

This output module measures 127 mm in height. Its width reaches 55 mm, and the depth equals 140 mm. The GE IC693MDL730E weighs approximately 0.34 kilograms. A single internal PCB holds all output switching and isolation circuits. The module provides twelve triac outputs for AC loads. It stores no energy in capacitors or internal batteries. One 48-pin front connector handles all field wiring connections. Twelve red LEDs display the real-time status of each channel.

Output Specifications and Electrical Ratings

The GE IC693MDL730E switches loads at 120 V AC or 240 V AC nominal. Each channel handles a continuous current of 2 A maximum. The total current per module reaches 8 A. Each output includes an internal snubber circuit for inductive loads. Consequently, this module reduces contact wear on external relays and contactors. The triac outputs switch at frequencies up to 15 Hz for cycling applications. Optical isolation separates the field side from the backplane logic. The module requires no external fuses for short-circuit protection.

Installation and Practical Application Tips

You must snap this module firmly into a standard 90-30 rack slot. Transitioning to wiring, use 0.5 mm² to 1.5 mm² stranded copper wire. The screw-type terminals require a 3 mm flathead screwdriver for tightening. For inductive AC loads, the internal snubbers provide adequate suppression. The operating temperature range extends from 0°C to 60°C reliably. This module consumes only 75 mA from the backplane bus.
