GE IC200CHS101A I/O Terminal

The GE IC200CHS101A functions as a passive termination base for VersaMax I/O modules. This terminal accepts field wiring from sensors and actuators. You will find it in distributed control systems across many industries. It provides screw-type connections for up to 16 discrete signal wires. Therefore, this unit simplifies maintenance and troubleshooting significantly.

This terminal measures 110 mm in height and 65 mm in width. Its depth reaches 50 mm for DIN rail mounting. The unit weighs approximately 0.18 kilograms. It contains no active electronic components at all. Sixteen screw terminals line up in two rows of eight. Additionally, you get a 16-pin header for I/O module connection.

Key Technical Specifications

Parameter	Value
Manufacturer	GE Intelligent Platforms
Model	IC200CHS101A
Product Type	I/O Terminal / Termination Base
Number of Terminals	16 (screw type)
Wire Gauge Range	24 to 16 AWG
Height	110 mm
Width	65 mm
Depth	50 mm
Weight	0.18 kg
Internal Components	0 (fully passive)
Energy Storage	0 Joules (none)
I/O Module Connection	16-pin header
Mounting Type	35 mm DIN rail
Operating Temperature	0°C to +55°C
Terminal Pitch	5 mm spacing

Internal Architecture and Energy Storage

The GE IC200CHS101A stores absolutely no electrical energy internally. It contains no capacitors, batteries, or semiconductor devices. Sixteen screw terminals connect directly to a 16-pin header through copper traces. Each trace provides a direct electrical path from the field wire to the I/O module. A plastic housing protects these traces from dust and moisture. The terminal accepts solid or stranded copper wire easily. You get two ground terminals for shield connection.

Connection Interfaces and Signal Wiring

You will find 16 screw terminals arranged in two horizontal rows. Each terminal accepts 24 to 16 AWG copper wire. Use a 3mm flathead screwdriver to loosen and tighten each screw. Strip 7 mm of insulation from each wire before insertion. Then, insert the bare copper into the terminal opening. Tighten the screw to 0.5 Nm of torque. The GE IC200CHS101A also includes a 16-pin female header. This header connects directly to any VersaMax I/O module. Align the header pins carefully before pressing the module down.

Installation and Mounting Steps

You mount this terminal onto standard 35 mm DIN rail. First, hook the top clip onto the rail edge. Then, push the bottom toward the rail until it snaps. Slide the terminal along the rail for easy positioning. Connect all field wiring before snapping on the I/O module. Label each terminal with its corresponding signal name. The GE IC200CHS101A requires no external power supply. It simply passes signals between field devices and the I/O module. For high-vibration areas, add end stops on both rail ends.
