GE HE693THM889 Thermocouple Input Module

The GE HE693THM889 is a high-performance thermocouple input module designed for Horner Electric’s PLC I/O series. This module features eight channels and delivers precise temperature measurements with a resolution of 0.5°C. It’s ideal for applications requiring reliable, multi-point temperature sensing in industrial environments.

Key Features of the GE HE693THM889 Thermocouple Input Module

• Part Number: HE693THM889
• Manufacturer: Horner Electric
• Product Line: PLC I/O
• Module Type: Thermocouple Input Module
• Resolution: 0.5°C
• Number of Channels: 8
• Input Impedance: > 20 MΩ
• A/D Conversion Time: 5 ms
• Power Consumption:
  • 70mA at 5VDC
  • 60mA at 24V relay
• Operating Temperature: 0 to 60°C (32°F to 140°F)
• Relative Humidity: 5% to 95% (non-condensing)

Technical Specifications

Description

The GE HE693THM889 is a specialized thermocouple input module designed for Horner Electric’s PLC I/O series. It supports eight channels for precise temperature measurement, ensuring accurate readings for various industrial processes. With a 0.5°C resolution, the module guarantees reliable performance in applications that require high levels of temperature sensitivity.

This module operates with a low power consumption of 70mA at 5VDC and 60mA at 24V relay, making it energy-efficient without compromising performance. Additionally, it offers >20 MΩ input impedance, which minimizes the loading effect on thermocouples. As a result, you will maintain accurate readings while extending the life of your temperature sensors.

With 5 ms A/D conversion time, the module provides rapid and precise signal processing, ideal for applications requiring real-time temperature monitoring. Whether in dynamic industrial processes or environments with varying conditions, this module ensures continuous, reliable operation.

The GE HE693THM889 can function within a wide temperature range of 0 to 60°C (32°F to 140°F) and can handle relative humidity levels from 5% to 95% as long as the environment remains non-condensing. This flexibility makes it suitable for a range of demanding industrial settings.

Applications

• Industrial Automation: Ideal for temperature monitoring in automated control systems.
• Real-Time Monitoring: Perfect for processes requiring precise and immediate temperature feedback.
• Manufacturing: Used in factories to manage temperature-sensitive operations.

Advantages

• High Precision: The 0.5°C resolution ensures consistently accurate temperature readings.
• Fast Data Processing: A/D conversion time of just 5 ms supports real-time applications.
• Wide Operating Range: Functions effectively in temperatures from 0°C to 60°C and in humid conditions.
• Energy Efficient: Consumes minimal power, with 70mA at 5VDC and 60mA at 24V.
