GE Fanuc IC660BBR100 Relay Output Block

Overview

The GE Fanuc IC660BBR100 relay output block provides reliable and efficient performance for industrial automation applications. It features 16 outputs, divided into 4 isolated groups, each containing 4 outputs. The block supports both AC and DC power, offering flexibility for various control systems. As part of the GE Fanuc Genius I-O product line, the IC660BBR100 ensures high durability and efficiency in demanding environments.

Technical Specifications

Specification	Details
Manufacturer	GE Fanuc (Emerson)
Product Type	Relay Output Block
Product Line	Genius I-O
Part Number	IC660BBR100
Weight	3.81 lbs (1.73 kg)
Output Block Type	Normally Closed
Number of Outputs	16
Output Configuration	4 Groups of 4 Outputs Each
Output Voltage Type	AC or DC
Power Requirements	87 mA at 115V AC
CPU Redundancy	Supported
Isolation Voltage Between Groups	1500 Volts
Operating Temperature	32°F to 140°F (0°C to 60°C)
Humidity Range	5% to 95% (Non-condensing)
Storage Temperature	-40°F to 212°F (-40°C to 100°C)

Key Features

16 Relay Outputs: The IC660BBR100 delivers 16 outputs, organized into 4 isolated groups. This design enhances control and minimizes interference between outputs.
Versatile Power Supply: You can operate the block with either AC or DC power, making it highly adaptable to different systems.
High Isolation Voltage: With a group-to-group isolation of 1500 Volts, the IC660BBR100 protects devices from electrical interference and ensures safe operation.
Compact and Durable: Measuring just 8.8 x 3.3 x 3.9 inches, this relay output block fits into most control panels, while its robust design ensures long-term reliability in industrial environments.
Temperature and Humidity Range: It operates optimally between 32°F and 140°F, with storage conditions supporting temperatures from -40°F to 212°F. Additionally, the block can endure a non-condensing humidity range of 5% to 95%.
Wide Compatibility: The block works with low-powered devices like lamps, contactors, and other relays that operate within a voltage range of 5–220 V DC or 5–250 V AC.

Applications

The IC660BBR100 relay output block is perfect for use in automation systems that require reliable and precise switching. Its versatile design makes it compatible with a wide range of control and indicator devices, ensuring smooth operation in various industrial settings.

Conclusion

The GE Fanuc IC660BBR100 relay output block offers a combination of flexibility, durability, and high performance. With 16 outputs, high isolation voltage, and compatibility with both AC and DC power, it remains a top choice for industrial automation needs.
