GE DS200PCCAG10A DS200PCCAG10ACB Signal Buffer

The GE DS200PCCAG10A DS200PCCAG10ACB serves as a proximity signal buffer board for the Mark V series. This board buffers and conditions signals from proximity probes for turbine monitoring. You will find this unit in many industrial power generation systems. General Electric designed this board for the Speedtronic turbine control platform. Its robust construction ensures reliable operation in harsh environments.

Technical Specifications

Parameter	Specification
Full Model Number	GE DS200PCCAG10A DS200PCCAG10ACB
Category	Proximity Signal Buffer Board for Speedtronic Turbine Control
Dimensions (W x H)	Approx. 8.5 x 6.8 inches
Weight	0.59 kg (1.30 lbs)
Number of Components	125+ discrete parts including buffer amplifiers and filters
Energy Storage	270 Joules (total capacitive discharge)
Interface Type	6x proximity probe inputs + 6x buffered output channels + 1x backplane connector

This board integrates over 125 discrete components onto a multi-layer PCB. Its dimensions measure roughly 8.5 inches wide by 6.8 inches high. The total weight reaches about 0.59 kilograms including the protective cover. Six proximity probe inputs connect directly to turbine shaft sensors. Six buffered output channels send conditioned signals to the controller. One backplane connector provides power and data paths to the main rack. The design stores up to 270 joules of capacitive energy for stable signal conditioning.

Functional Layout and Signal Buffering

The GE DS200PCCAG10A DS200PCCAG10ACB buffers proximity signals with high fidelity and low noise. Each buffer amplifier maintains signal integrity over long cable runs. Moreover, the board filters high-frequency interference before passing signals forward. This variant includes upgraded buffers for better linearity and response time. General Electric specifically designed this buffer board for the Mark V Speedtronic system. You can replace an older board with this unit without changing the rack configuration.

Installation Guidelines and Compatibility

This proximity signal buffer board mounts directly into a standard Mark V rack slot. Always disconnect system power before handling the GE DS200PCCAG10A DS200PCCAG10ACB. The board works with existing GE Mark V backplanes and proximity probes. Verify your firmware revision supports this variant. This board maintains backward compatibility with earlier Mark V versions. Proper installation ensures accurate shaft position monitoring and system protection.
