GE DS200CTBAG1ADD Terminal Board for Mark V Speedtronic System

Overview

The GE DS200CTBAG1ADD is a Terminal Board designed specifically for use with the Mark V Speedtronic system. It serves as a key interface for connecting and managing a wide range of electrical inputs and outputs within the control system. This module supports smooth integration and reliable operation, enabling efficient signal management for industrial applications.

Key Features

• Manufacturer: General Electric
• Model: DS200CTBAG1ADD
• Category: Terminal Board for Mark V Speedtronic System
• Input Voltage: 125 VDC
• Connectors:
  • 1 x 40-pin connector (D: JFF)
  • 1 x Serial connector
• Signal Inputs:
  • 6 x Magnetic Pulse Rate Inputs
  • 6 x Excitation Sources for LVDTs
• Signal Outputs:
  • 8 x Servo Value Outputs
• Terminal Blocks:
  • 2 terminal blocks, each supporting 72 signal wires
• Environmental Conditions:
  • Operating Temperature: -20°C to +70°C (-4°F to +158°F)
  • Humidity: 5% to 95%, non-condensing

Technical Specifications

Functionality and Applications

The GE DS200CTBAG1ADD terminal board is integral to the Mark V Speedtronic system, which is used in industrial and power generation applications. It connects various signal inputs and outputs, such as magnetic pulse rates, servo values, and LVDT excitation sources, to ensure smooth operation and control. With a 40-pin connector and serial connector, it offers versatility in managing electrical signals.

This terminal board is built to operate under harsh industrial conditions, with an operating temperature range of -20°C to +70°C and humidity tolerance from 5% to 95% non-condensing. Its compact design allows it to fit easily within control cabinets or racks, making it a convenient and efficient solution for various control system setups.

Advantages

• Efficient Signal Management: The board connects multiple signals and outputs to the Mark V Speedtronic system.
• High Voltage Input Support: It supports 125 VDC input voltage, suitable for many industrial environments.
• Wide Operating Temperature: Designed to function in temperatures ranging from -20°C to +70°C, ideal for various industrial conditions.
• Easy Installation: The DIN rail or standard panel mounting options ensure hassle-free installation.
• Robust Construction: Built to withstand demanding conditions such as temperature extremes and high humidity.

Applications

The GE DS200CTBAG1ADD is commonly used in industrial settings such as:

• Power generation systems
• Combustion control systems
• Oil & gas industry
• Water treatment plants
• Steel production and other heavy industries
  Its versatility and robust design make it essential for controlling and managing complex processes in these sectors.
