GE A16B-2200-0360/02A Axes Circuit Board for CNC Motion Control

The GE A16B-2200-0360/02A controls servo motor movement for multiple CNC axes. You can install this board into the main CNC rack of Series 15 or 16 controllers. It processes position commands and encoder feedback signals in real time. This board suits machining centers, lathes, and high-speed milling applications.

Technical Specifications and Hardware Layout

This axes circuit board measures 260 mm in height. Its width reaches 210 mm, and the depth equals 35 mm. The GE A16B-2200-0360/02A weighs approximately 0.60 kilograms. A single multilayer PCB holds all motion control and interface circuits. The board contains no energy storage capacitors or batteries. Four 34-pin ribbon connectors provide encoder feedback inputs. Two 50-pin headers handle servo command outputs to amplifiers. Six test points allow signal monitoring with oscilloscope probes.

Axis Control Capabilities and Performance

The GE A16B-2200-0360/02A controls up to four axes of simultaneous motion. It reads encoder feedback at frequencies up to 1 MHz. This board generates analog command voltages from -10 V to +10 V for servo amplifiers. Consequently, it supports high-precision positioning and contouring operations. The board includes a built-in position error monitoring circuit. It communicates with the main CNC processor through a high-speed bus. The board handles acceleration, deceleration, and backlash compensation automatically.

Installation and Diagnostic Features

You must insert this board firmly into a dedicated CNC rack slot. Transitioning to wiring, route encoder cables away from motor power cables. The board includes LED indicators for axis enable and fault status. For troubleshooting, use the six test points with an oscilloscope. Always power off the system before removing or inserting the board. The operating temperature range spans from 0°C to 55°C reliably.
