FUJI NU2X3206-W Power Supply Module

This power supply module delivers stable DC power for Fuji Electric control systems. The FUJI NU2X3206-W converts AC input into regulated output voltages for connected components. Its robust design ensures reliable operation in demanding industrial environments.

Key Technical Specifications

Parameter	Specification
Model	FUJI NU2X3206-W
Type	Power Supply Module
Input Voltage	100 to 240V AC
Input Frequency	50/60 Hz
Output Voltage	24V DC
Output Current	3.2 A
Dimensions	112 mm × 98 mm × 75 mm
Weight	Approximately 0.92 kg
Mounting	I/O rack compatible

Reliable Power Conversion

The FUJI NU2X3206-W accepts a wide input range from 100 to 240V AC at 50 or 60 Hz. This flexibility allows deployment across different regional power grids without modification. Furthermore, the unit delivers a regulated 24V DC output with up to 3.2 amperes of continuous current. Engineers can rely on this supply for powering I/O modules, sensors, and other field devices.

The internal topology incorporates high-quality capacitors for energy storage during momentary interruptions. This storage provides ride-through capability without disrupting system operation. Additionally, the FUJI NU2X3206-W includes overcurrent and short-circuit protection circuits. These protective features safeguard both the power supply and connected equipment from electrical faults.

Robust Physical Construction

This power supply module measures 112 millimeters in height with a compact depth profile. Its weight of approximately 0.92 kilograms reflects the robust internal components and thermal management. The housing utilizes durable materials that dissipate heat effectively during continuous operation. Fuji Electric designed this unit for long-term reliability in industrial control cabinets.

Technicians will appreciate the clearly labeled input and output terminals on the module. These terminals accept standard gauge wires for secure and straightforward connections. Furthermore, status indicators provide visual confirmation of input power and output presence. Operators can verify proper operation without using diagnostic tools.

System Integration and Application

The FUJI NU2X3206-W mounts directly into standard Fuji Electric I/O racks. This integration eliminates the need for external power distribution components within the enclosure. The module aligns seamlessly with CPU, input, and output units for a unified control solution. Industries such as automotive assembly, packaging machinery, and material handling frequently deploy this power supply module for reliable system power distribution.
