Board Overview
This remote module collects field signals and sends them to a main controller. You can install FUJI NR1SW-16T65DT/NR1JW in distributed I/O stations away from the central rack. The unit processes 16 digital inputs locally and transmits data via RS-485. It reduces wiring costs by placing I/O near field sensors.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions (W x H x D) | 110 mm x 75 mm x 65 mm |
| Weight | 0.29 kg |
| Digital inputs | 16 points (24V DC, sink/source) |
| Input response time | 10 ms (filter adjustable) |
| Communication protocol | Modbus RTU |
| Communication port | RS-485 (2-wire, half-duplex) |
| Baud rate | 9600 to 115200 bps |
| Maximum network length | 1200 meters |
| Node address range | 1 to 247 (DIP switch set) |
| Status indicators | Power, run, comm error, I/O LEDs |
| Total onboard components | 145 discrete parts |
| Energy storage type | Ceramic and electrolytic capacitors |
| Energy storage rating | 150 µF at 25V DC |
| Operating temperature | -10°C to +55°C |
Board Layout and Components
The PCB separates the communication section from input circuits physically. Sixteen optoisolators provide galvanic isolation for every input channel. Moreover, 145 discrete components include transient suppressors and power regulation. Electrolytic capacitors stabilize the internal DC supply rails. Consequently, the module rejects electrical noise from long field cables.
Installation Process
You can mount FUJI NR1SW-16T65DT NR1JW on a standard 35 mm DIN rail. The RS-485 port connects directly to a Modbus RTU master device. Furthermore, a removable screw terminal block accepts wiring for all 16 input points. DIP switches allow easy configuration of node address and baud rate.
Performance Advantages
This module transmits input status to the master every 20 milliseconds typically. The adjustable 10 ms input filter rejects contact bounce effectively. Therefore, remote monitoring applications receive stable, error-free data. The long 1200-meter network distance also covers large factory floors easily.
Safety and Compliance
FUJI NR1SW-16T65DT NR1JW meets CE and RoHS industrial standards. The unit stores negligible electrical energy after power removal. Hence, technicians face no capacitor discharge hazards during field servicing.
