Fuji NP1AX08-MR Analog I/O Module

Mixed Analog Signals for Process Control

This analog module handles both input and output signals in one compact unit. The Fuji NP1AX08-MR provides four analog inputs and four analog outputs for your system. It accepts voltage or current signals from sensors and transmitters. The outputs drive actuators, valves, and variable frequency drives directly. Consequently, this module saves rack space for mixed analog applications.

Input & Output Specifications

The Fuji NP1AX08-MR converts analog signals to 12-bit digital values for the CPU. You can configure each channel individually for voltage or current ranges. The inputs accept 0 to 10V DC, -10 to +10V DC, or 4 to 20 mA. Outputs provide 0 to 10V DC or 4 to 20 mA for field devices. Therefore, this module suits temperature control, pressure regulation, and flow monitoring.

Parameter	Detailed Specification
Operating Temperature	0°C to +55°C
Storage Temperature	-25°C to +70°C
Humidity Range	20% to 95% RH (no condensation)
Analog Inputs	4 channels
Analog Outputs	4 channels
Resolution	12 bits (4096 counts)
Input Ranges	0-10V, -10-+10V, 4-20 mA
Output Ranges	0-10V, 4-20 mA
Input Impedance	1 MΩ (voltage), 250 Ω (current)
Output Load	5 kΩ min (voltage), 600 Ω max (current)
Conversion Speed	2 ms per channel
Accuracy	±0.5% of full scale
Status LEDs	2 (POWER, READY)
Compatible Rack	MICREX-SX (any slot)
Power Supply	24V DC via backplane + external
Current Draw	200 mA typical
Energy Storage	None (no battery or capacitor)

Installation & Field Wiring

You insert the Fuji NP1AX08-MR into any available slot of your MICREX-SX rack. Connect your analog sensors to the four input terminals on the top row. Wire your actuators to the four output terminals on the bottom row. Apply 24V DC external power to the dedicated supply terminals. The CPU reads input values and writes output values automatically each scan.

Operational Advantages & Mixed I/O Benefits

The Fuji NP1AX08-MR eliminates the need for separate input and output cards. This compact design leaves more rack space for other functions. The module provides electrical isolation between channels and the backplane. LED indicators confirm normal module operation at a single glance. Therefore, this analog I/O module offers a cost-effective solution for mixed signal applications.
