Fuji FTK374D-C10 Expansion Module

Add More I/O Points to Your MICREX-F System

This expansion module increases the I/O capacity of your existing MICREX-F controller. The Fuji FTK374D-C10 connects to the main unit via a simple ribbon cable. It provides additional input and output points for growing automation needs. A built‑in status LED indicates normal communication with the base unit. Consequently, this module allows system expansion without replacing your current PLC.

I/O Configuration & Physical Design

The Fuji FTK374D-C10 mounts directly on a standard DIN rail inside your panel. You can connect up to three expansion modules to a single base unit. A short ribbon cable carries power and communication between modules. The unit operates reliably in temperatures from 0°C to 55°C. Therefore, this expansion solution suits conveyor systems, packaging lines, and small assembly machines.

Parameter	Detailed Specification
Operating Temperature	0°C to +55°C
Storage Temperature	-20°C to +70°C
Humidity Range	20% to 90% RH (no condensation)
Digital Inputs	16 points (24V DC, sink/source)
Digital Outputs	8 points (relay, 2A per point)
Total I/O Points	24 points
Max Expansion per System	3 modules (72 additional I/O)
Connection Type	Ribbon cable (included)
Cable Length	10 cm (standard)
Status LEDs	1 green (POWER/COM)
Output Type	Relay (form A, normally open)
Output Contact Life	100,000 operations (rated load)
Compatible Base Units	MICREX-F series (FTK models)
Power Supply	24V DC via ribbon cable
Current Draw	50 mA typical
Energy Storage	None (no battery or capacitor)

Installation & System Integration

You mount the Fuji FTK374D-C10 on a DIN rail next to your base unit. Connect the ribbon cable between the expansion port and the main unit. The system automatically recognizes the new module after power‑up. You then wire your field devices to the 24 screw terminals. No additional configuration or programming steps are necessary.

Operational Advantages & Expansion Flexibility

The Fuji FTK374D-C10 allows you to start with a small system and grow gradually. You can add one module today and another module next year as needed. The relay outputs handle 2A loads suitable for small motors and solenoids. Each output provides physical isolation between PLC circuits and field devices. Therefore, this expansion module offers a cost‑effective path for system growth.
