FUJI FSB126H Mount Board Unit for MICREX-F System

The FUJI FSB126H serves as a sturdy mounting platform for PLC components. This mount board unit works within the MICREX-F automation family. It holds various modules in a fixed vertical orientation. You can use it to organize your control cabinet efficiently.

Key Technical Specifications

Below you will find the accurate technical parameters for the FUJI FSB126H.

The board measures 260 mm in width and 210 mm in height. Its total depth reaches 15 mm. The FUJI FSB126H weighs approximately 1.1 kg. This unit contains a single steel plate with pre-drilled mounting holes. Energy storage does not apply to this mechanical component.

You will find eight threaded holes on the board surface. These holes accept M4 screws for module attachment. Consequently, you can secure your modules without drilling additional holes. The anti-corrosion coating protects against humidity and mild contaminants.

Installation and System Integration

You can mount the FUJI FSB126H inside any standard control cabinet. The board requires four screws for secure wall or panel attachment. Therefore, installation takes only a few minutes. The vertical orientation promotes natural airflow around all components.
