Foxboro FBM223 Universal Input Module

Overview

The Foxboro FBM223 is a highly versatile 16-channel universal input module designed for use with the Foxboro I/A Series Distributed Control System (DCS). It supports multiple input signal types, including voltage, current, RTD, and thermocouple, making it an ideal choice for a wide range of industrial applications. The FBM223 delivers precise data acquisition, ensuring reliable performance in even the most challenging environments.

Key Features

16-Channel Universal Input Module: Accepts a wide variety of input signals such as 0-10 V, 4-20 mA, 0-100 Ω, and thermocouples.
High Accuracy: Offers an accuracy of +0.05% of full scale for precise signal conversion.
Wide Input Range: Supports various signal types, including voltage, current, RTD, and thermocouples.
Galvanic Isolation: Provides 1500 V isolation for each channel, minimizing interference and ensuring data integrity.
Rugged Enclosure: The FBM223 is housed in a durable NEMA 4, IP66 rated enclosure, suitable for harsh industrial environments.
Compact Design: Its small form factor allows for easy installation in tight spaces, optimizing panel space.

Technical Specifications

Specification	Value
Manufacturer	Foxboro
Model Number	FBM223
Product Type	Universal Input Module
Number of Channels	16
Input Range	0-10 V, 4-20 mA, 0-100 Ω, Thermocouples
Accuracy	+0.05% of full scale
Resolution	12 bits
Update Rate	100 ms
Galvanic Isolation	1500 V
Operating Temperature Range	-40°C to +85°C
Enclosure Rating	NEMA 4, IP66

Applications

The Foxboro FBM223 is ideal for a range of industrial environments, including:

Industrial Processes: Suitable for power generation, oil and gas production, and chemical processing.
HVAC Systems: Efficient data acquisition for temperature, humidity, and pressure measurements.
Food and Beverage Processing: Ensures precise control over processing conditions.
Pharmaceutical Manufacturing: Maintains accuracy and reliability in critical production environments.

Conclusion

The Foxboro FBM223 provides an efficient and reliable solution for acquiring data from a wide range of industrial inputs. With high accuracy, rugged construction, and versatile signal compatibility, it is an essential component for modern automation systems.
