Emerson 12P2532X072 KJ3222X1-BA1: High-Performance Discrete Output Module for DeltaV Systems

Overview

The Emerson 12P2532X072 KJ3222X1-BA1 is a robust discrete output module designed for use within Emerson DeltaV control systems. This module features 12 discrete outputs and is essential for controlling field devices such as actuators, relays, and valves. With its high reliability and excellent performance, it is ideal for demanding industrial environments, including process control, manufacturing, and power generation applications.

Key Features and Specifications

Manufacturer: Emerson

Model Number: 12P2532X072 KJ3222X1-BA1

Category: Discrete Output Module

Technical Specifications

Power Specifications

• Local Bus Power Rating: 12 VDC at 150 mA
• Bussed Field Power Rating: 24 VDC at 300 mA
• Field Circuit Rating: 24 VDC at 30 mA per channel

Environmental Specifications

• Operating Temperature Range: -40°C to +70°C
• Relative Humidity: 5% to 95% Non-condensing
• Ingress Protection: IP 20

Physical Specifications

• Shock Resistance: 10 g half-sine wave for 11 ms
• Vibration Resistance: 1 mm peak-to-peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz
• Terminal Block Key Position: A1

Features

• High Reliability: The module provides excellent performance and ensures reliable control of field devices.
• Compact and Efficient: Its small form factor allows for easy installation in tight spaces, without compromising functionality.
• Wide Operating Temperature Range: It can operate in extreme environments, with an ambient temperature range of -40°C to +70°C.
• Protection Features: The module includes built-in protection mechanisms to safeguard both the system and connected devices.
• Versatile Communication: Compatible with a variety of communication protocols, ensuring seamless integration with Emerson DeltaV systems.

Applications

The Emerson 12P2532X072 KJ3222X1-BA1 is widely used in various industrial automation applications, including:

• Process Control: Provides reliable control for industrial process systems.
• Manufacturing Automation: Drives discrete outputs to enhance the automation of manufacturing processes.
• Power Generation: Controls critical field devices in power generation systems.
• Oil and Gas: Facilitates the operation of devices in exploration and production settings.
• Building Automation: Ensures efficient operation of building systems through reliable output control.
