Chassis System Overview
The Bently Nevada 3500/05-01-02-00-00-00 provides the physical enclosure for the 3500 series monitoring system components. This rack houses power supplies, monitoring modules, and communication interfaces in a single chassis. Its robust construction supports continuous operation in demanding industrial environments. Machinery protection installations rely on this rack for organized system architecture.
Technical Specifications
The 3500/05-01-02-00-00-00 measures 482.6 mm in width and 266.7 mm in height. Its 19-inch rack-mount format fits standard industrial cabinets globally. The chassis weighs approximately 6.8 kilograms when fully populated. It requires a 24V DC or AC power input depending on the power supply module.
| Parameter | Specification |
|---|---|
| Model | 3500/05-01-02-00-00-00 |
| Product Type | System Rack (Chassis) |
| Dimensions | 482.6 mm x 266.7 mm x 320 mm (depth) |
| Weight | ~6.8 kg (empty) |
| Rack Format | 19-inch (EIA) |
| Height Units | 6U |
| Slot Positions | 15 (full-height) |
| Compatible Modules | Power supplies, monitoring modules, keyphasor, comms |
| Backplane | Integrated with all required buses |
| Connector Type | Edge connectors for module insertion |
| Mounting Type | Rack-mount (front flanges) |
| Material | Cold-rolled steel with powder coating |
| Cooling | Integral fan tray (optional) |
| LED Indicators | None (relies on module LEDs) |
| Operating Temp. | -30°C to +65°C |
Rack Architecture and Slot Configuration
This system rack provides fifteen slots for full-height 3500 series modules. The first slot typically holds the power supply module. Slot 2 accommodates the keyphasor or communication processor. Remaining slots take monitoring modules for various measurement types. The integrated backplane handles all power and signal distribution. This architecture supports flexible, user-defined system configurations.
Installation and Cabinet Integration
Installing the Bently Nevada 3500/05-01-02-00-00-00 requires standard 19-inch cabinet rails. The rack slides into the cabinet and secures with four mounting bolts. You must provide adequate clearance for the 320 mm depth. Proper ventilation around the rack ensures effective cooling. The chassis includes grounding studs for protective earth connection. The rack fits most standard control cabinets without modification.
Module Installation and Maintenance
Inserting modules into the requires no special tools. Each module slides into its slot and locks via the front-panel retaining screws. The backplane automatically provides the correct signals. Hot-swappable support allows changing modules with power applied. This feature minimizes system downtime during maintenance. Routine checks include verifying module seating and inspecting for dust accumulation.
Reliability and Environmental Performance
The Bently Nevada meets stringent environmental specifications. Its steel construction withstands vibration and shock in plant settings. The wide operating temperature range supports outdoor and remote installations. The rack’s design ensures electromagnetic compatibility with nearby equipment. Regular maintenance preserves long-term structural integrity.
