Bently Nevada 3300/16-13-01-00-00-00-00 Dual Vibration Monitor

The Bently Nevada 3300/16-13-01-00-00-00-00 is a highly reliable Dual Vibration Monitor designed to continuously measure and monitor radial vibration and shaft position (gap) across two independent channels. This monitor accepts inputs from two proximity probe systems, ensuring precise and real-time data collection for optimal machine performance. It supersedes the older 3300/15 Dual Radial Vibration Monitor by providing enhanced capabilities, including radial position gap alarms, which the previous model lacked.

Key Features

Dual Channel Monitoring: Monitors both radial vibration and shaft position (gap) simultaneously for comprehensive machine health assessment.
Improved Alarm Functionality: Provides gap alarms to alert operators to potential mechanical issues.
Enhanced Sensitivity: Allows for user-programmable sensitivity of 100 mV/mil (4 V/mm) or 200 mV/mil (8 V/mm), offering flexibility for different monitoring needs.
Precise Signal Conditioning: Ensures high accuracy, with a typical accuracy of ±0.33% at 25°C (+77°F).
Recorder Outputs: Supports multiple output types, including current and voltage outputs, with individual recorder outputs for each channel.
Reliable Power Supply: Low power consumption of 2 watts nominal, providing energy-efficient operation in demanding industrial environments.

Applications

The 3300/16-13-01-00-00-00-00 is ideal for monitoring vibration in critical rotating machinery, including:

Turbines: Detects and prevents issues in turbine shafts by measuring vibration and gap.
Motors and Pumps: Monitors axial and radial vibration to safeguard motor health.
Industrial Equipment: Offers reliable monitoring in refineries, power plants, and other heavy machinery applications.

Technical Specifications

Specification	Details
Model Number	3300/16-13-01-00-00-00-00
Manufacturer	Bently Nevada
Product Type	Dual Vibration Monitor
Input Signal	One or two proximity probe signals
Input Impedance	10 kΩ
Sensitivity	100 mV/mil (4 V/mm) or 200 mV/mil (8 V/mm)
Power Consumption	2 watts (nominal)
Signal Conditioning Accuracy	±0.33% typical, ±1% maximum at +25°C (+77°F)
Recorder Output Types	+4 to +20 mA, 0 to -10 Vdc, +1 to +5 Vdc
Recorder Accuracy	±0.7% for +4 to +20 mA, ±0.09 mA offset
	±1.1% for voltage outputs, ±10 mV offset for +1 to +5 Vdc
Output Impedance	100 Ω for voltage outputs
Voltage Compliance (Current Outputs)	0 to +12 Vdc range across load
Load Resistance (Current Output)	0 to 600 Ω when using +4 to +20 mA option
Minimum Load Resistance	10 kΩ

Dimensions and Weight

Dimensions: 5.2″ x 3.2″ x 1.8″ (13.2 cm x 8.1 cm x 4.5 cm)
Weight: Approx. 3.5 kg (7.7 lbs), ensuring easy installation and maintenance in industrial environments.
