Bently Nevada 16925-30 | Seismic Transmitter

Product Overview

The 16925-30 operates as a seismic transmitter within the Bently Nevada monitoring lineup. This unit converts velocity signals from seismic transducers into proportional 4–20 mA outputs. Consequently, plant operators gain continuous vibration monitoring for cooling towers, fans, and balance-of-plant machinery.

Technical Specifications

Parameter	Value
Module Type	Seismic transmitter
Input Type	Velocity seismic transducer
Output Signal	4–20 mA proportional
Power Supply	24 V DC nominal
Operating Temperature	-35°C to +85°C
Storage Temperature	-40°C to +100°C
Frequency Response	4.5 Hz to 1 kHz
Mounting Type	Panel or housing mount
Weight	Approximately 400 g
Dimensions	120 mm × 80 mm × 30 mm
Housing Material	Aluminum enclosure
Terminal Type	Screw terminals
Accuracy	±2% of full scale

Construction and Materials

The housing uses aluminum, which shields internal electronics from electromagnetic noise. Meanwhile, screw terminals accept standard field wiring without specialized tools. The compact enclosure fits existing cabinets, so retrofits require minimal downtime.

Interface and System Compatibility

This transmitter accepts signals from Bently Nevada seismic transducers. Additionally, the 4–20 mA output interfaces directly with PLCs and DCS platforms. Therefore, users integrate vibration data into existing control systems easily.

Installation Guidelines

Mount the unit away from excessive heat and strong electromagnetic sources. Furthermore, route input and output wiring separately to reduce noise coupling. Correct grounding practice improves measurement stability, so follow plant standards carefully.
