Bently Nevada 16699-10-02-01 Velocity Seismoprobe

Product Identity

Brand: Bently Nevada
Model: 16699-10-02-01
Category: Velocity Seismoprobe

Technical Specifications

Overview

The 16699-10-02-01 functions as an absolute casing vibration sensor within the Bently Nevada Velocity Seismoprobe line. It converts mechanical motion into a proportional AC voltage signal. Therefore, engineers rely on it for machinery protection and condition monitoring. This transducer operates without external power because its moving coil generates voltage inside a magnetic field. Consequently, wiring stays simple in remote or hazardous installations. The sealed housing also resists oil, dust, and mechanical shock.

How It Works

Inside the sensor, a precisely wound coil suspends on a spring mechanism around a permanent magnet. When the machine casing vibrates, the coil moves relative to the magnet. This relative motion induces a voltage that mirrors vibration velocity. As a result, the output signal directly reflects machine behavior without amplification. The design contains no active electronics, so it delivers excellent long-term stability. Furthermore, the passive architecture avoids drift issues common in powered sensors.

Mounting and Installation

Operators typically mount the 16699-10-02-01 on bearing housings or structural frames. The 1/4-28 UNF threaded stud provides a secure mechanical connection. Meanwhile, the 2-pin military-style connector ensures reliable signal transmission. Proper surface preparation matters greatly for accurate velocity readings. Therefore, technicians should mount the sensor perpendicular to the measured axis. Additionally, torque specifications protect the housing from stress damage.
