Technical Specifications and Hardware Overview
The Bently Nevada 149356-01 serves as a display router box module for the 3500 series monitoring system. This module measures 220 mm in height, 150 mm in width, and 80 mm in depth for compact panel mounting. It weighs approximately 1.8 kilograms, which requires careful handling during installation. The unit draws 0.5 A from a 24 V DC supply, consuming roughly 12 W under normal operation. It features 2 Ethernet ports for network connectivity and data routing. The module includes 2 RS-232 serial ports for local device communication.
It provides 4 video output ports for external display connectivity. The unit contains 4 MB of flash memory for firmware and configuration storage. It includes 2 MB of RAM for data buffering and routing operations. The module supports data transfer rates up to 10/100 Mbps on the Ethernet interfaces. It routes display data to multiple monitors simultaneously. The unit includes LED indicators for power and port activity status. The operating temperature range spans 0°C to 50°C for indoor environments. Storage temperatures extend from -20°C to 70°C without causing component damage. Humidity tolerance covers 10% to 90% non-condensing conditions.
| Parameter | Specification |
|---|---|
| Brand | Bently Nevada |
| Model | 149356-01 |
| Category | Display Router Box Module |
| Dimensions (H×W×D) | 220 × 150 × 80 mm |
| Weight | 1.8 kg |
| Power Supply | 24 V DC, 0.5 A (12 W) |
| Ethernet Ports | 2 × 10/100 Mbps |
| Serial Ports | 2 × RS-232 |
| Video Outputs | 4 ports |
| Flash Memory | 4 MB |
| RAM | 2 MB |
| Protocol Support | TCP/IP, Modbus |
| Display Support | Multi-screen routing |
| LED Indicators | Power and port activity |
| Operating Temp | 0°C to 50°C |
| Storage Temp | -20°C to 70°C |
| Humidity | 10–90% RH (non-condensing) |
| Certifications | CE, FCC |
Display Routing and Connectivity Features
This router box distributes display data from the monitoring system to multiple screens. It manages video signal routing for operator workstations and control rooms. The Bently Nevada 149356-01 supports 4 independent video output channels for flexible display setups. It provides 10/100 Mbps Ethernet connectivity for network-based data transfer. The module includes RS-232 ports for legacy device communication and configuration. It stores routing configurations in onboard flash memory for reliable operation. The unit supports both local and remote display management options.
Installation and Application Details
The 149356-01 mounts directly onto a DIN rail or panel surface. It requires 40 mm clearance above and below for adequate airflow. The module connects to displays via standard video cables and connectors. It interfaces with the 3500 system through Ethernet network links. The unit delivers a mean time between failures of 100,000 hours. It carries CE and FCC certifications for global deployment. The module passes vibration testing at 10 to 55 Hz with 0.15 mm amplitude. It withstands shock loads up to 5 g for 30 ms duration.
