Bently Nevada 1034549-10 Power Supply Module

The 1034549-10 power supply module from Bently Nevada feeds machinery protection racks and field monitoring equipment with regulated DC power. Plant engineers install this unit whenever a monitoring cabinet needs a dependable, dedicated supply. Consequently, it keeps vibration, position, and speed channels running without interruption.

Key Technical Specifications

The table below outlines the main physical and electrical parameters of the 1034549-10 module.

Parameter	Specification
Product Type	Power Supply Module
Compatibility	Bently Nevada machinery protection systems
Dimensions	Approximately 250 mm x 130 mm x 60 mm
Weight	Approximately 1.3 kg (2.9 lbs)
Mounting	Rack frame or panel mounting base
Interface	Backplane power bus and status indicator lines
Connectors	Multi-pin connector and screw terminal blocks
Component Count	Multiple regulators, transformers, and protection circuits
Energy Storage	Bulk capacitors for voltage ride-through
Input Voltage	Wide-range AC mains input
Output Rails	Multiple regulated DC output voltages
Operating Temperature	0 degrees C to 60 degrees C
Storage Temperature	-40 degrees C to 85 degrees C
Humidity	5% to 95% non-condensing

Functional Overview

This module converts AC mains power into clean, isolated DC rails for downstream monitors. Therefore, it shields sensitive measurement circuits from ripple and line transients. The 1034549-10 also monitors output status and signals faults through front-panel indicators. Meanwhile, its onboard energy storage sustains output during brief input interruptions.

Installation and Handling Notes

Always verify input voltage and polarity before connecting the 1034549-10 to a live rack. In addition, inspect bulk capacitors for swelling or leakage during routine service. Tighten all power terminals to the specified torque value. Finally, record measured rail voltages in your maintenance log.
