ABB DSBC174 3BSE012211R1 – Bus Extender Module

The ABB DSBC174 3BSE012211R1 is an advanced bus extender module that facilitates long-distance communication in S100 I/O systems. This module plays a crucial role in expanding the communication range, ensuring reliable data transfer between remote I/O modules. By enhancing the capabilities of distributed system architectures, it supports modular and efficient data transmission across industrial automation environments.

Key Features:

Extended Communication Range: The DSBC174 increases the communication distance between I/O modules, ensuring that all devices remain connected over larger spans.
Seamless Integration: It integrates effortlessly with ABB’s S100-based Distributed Control Systems (DCS), supporting modular automation configurations for scalable solutions.
Consistent Data Transfer: This bus extender guarantees stable, uninterrupted data transmission, which is essential for system integrity in complex control networks.
Space-Saving Design: With a slim profile, the DSBC174 fits easily within control cabinets, optimizing space without compromising on performance.

Technical Specifications:

Specification	Details
Model Number	DSBC174 3BSE012211R1
Product Type	Bus Extender Module
System Compatibility	ABB S100 I/O Bus
Length	360 mm
Width	260 mm
Height	20 mm
Weight	0.34 kg
Use	Extends communication range for I/O modules
Installation	Mounted inside control cabinets
Power Requirements	Powered through the S100 I/O bus
RoHS Compliance	Not RoHS Compliant
WEEE Category	5 (Small Equipment)
Batteries Included	None

Environmental & Compliance:

RoHS: Not RoHS compliant.
WEEE Category: Category 5 – Small Equipment.
Batteries: No batteries are included with the module.

Applications:

The ABB DSBC174 3BSE012211R1 is ideal for systems that require extended communication ranges. It ensures efficient and reliable data transfer in a variety of industrial automation setups, including:

Distributed Control Systems (DCS) for large-scale automation networks.
Remote I/O communication where data integrity is essential over long distances.
Modular control systems that require easy integration and expansion within ABB S100-based systems.

Conclusion:

By using the ABB DSBC174 3BSE012211R1, you can extend the communication capabilities of your S100 I/O systems. This module ensures reliable long-distance communication, optimizing your control system and enhancing its scalability.
