ABB DSAI155 57120001-HZ 14-Channel Thermocouple Module

The ABB DSAI155 57120001-HZ is a high-precision 14-channel thermocouple module, designed to offer accurate analog signal processing for industrial automation systems. This analog input board ensures reliable data acquisition and integrates seamlessly into various control systems, providing consistent and efficient performance. It is specifically built to handle thermocouple inputs, making it ideal for temperature measurement and monitoring in industrial settings.

Designed for industrial environments, the DSAI155 features a compact design and operates efficiently within a wide range of temperatures. It is a crucial component for systems requiring high accuracy and durable performance. With its IP20 rating, it provides adequate protection against dust and contact with live parts, making it suitable for factory floors and other harsh environments.

Key Features and Specifications:

Product ID: 57120001-HZ
Manufacturer: ABB
Type Designation: DSAI155
Catalog Description: DSAI155 57120001-HZ 14-Channel Thermocouple Module
Product Type: Analog Input Board
Channels: 14 channels for thermocouples
Input Range: -10V to +10V
Accuracy: ±0.25%
Power Consumption: 2W
Operating Temperature: -25°C to +70°C
Environmental Rating: IP20 for industrial environments
RoHS Status: Not RoHS Compliant
WEEE Category: 5 (Small Equipment with no external dimension more than 50cm)
Country of Origin: Sweden
Product Net Weight: 0.5 kg

Technical Specifications:

Parameter	Value
Product Name	ABB DSAI155 14-Channel Thermocouple Module
Product ID	57120001-HZ
Manufacturer	ABB
Product Type	Analog Input Board
Channels	14 (for thermocouples)
Input Range	-10V to +10V
Accuracy	±0.25%
Power Consumption	2W
Operating Temperature	-25°C to +70°C
Environmental Rating	IP20
RoHS Compliance	Not RoHS Compliant
WEEE Category	5 (Small Equipment)
Net Weight	0.5 kg
Country of Origin	Sweden

Product Dimensions:

Depth/Length: 255 mm
Height: 15 mm
Width: 363 mm
Net Weight: 0.5 kg

Environmental Compliance:

RoHS Status: Not RoHS Compliant
WEEE Category: 5 (Small Equipment – No external dimension exceeding 50 cm)

Application:

The ABB DSAI155 57120001-HZ is widely used in industrial automation systems that require high-accuracy temperature measurements. Its 14 thermocouple channels make it a suitable choice for monitoring temperature in various processes. Thanks to its compact design and IP20 rating, it is ideal for use in harsh industrial environments, offering excellent protection and performance.
