ABB DSAI110 57120001-DP Analog Input Module

The ABB DSAI110 57120001-DP is a highly efficient analog input module, specifically designed for capturing and processing analog signals in industrial control systems. It integrates seamlessly with the ABB Advant Master Process Control System, ensuring precise and reliable performance.

With 32 channels, the ABB DSAI110 57120001-DP can handle various signal types. Additionally, it delivers high accuracy and includes galvanic isolation between channels and the power supply, which improves signal integrity. Moreover, the module’s DIN rail mounting design allows for easy and flexible installation in industrial environments.

Key Features and Specifications:

• Product Name: ABB DSAI110 57120001-DP Analog Input Unit
• Product ID: 57122201-DP
• Manufacturer: ABB
• Type Designation: DSAI110 57120001-DP
• Number of Channels: 32
• Supported Signal Types:
  • ±10 V
  • ±20 mA
  • Thermocouples (specific types may vary)
  • RTDs (some types may require additional configuration)
• Resolution: 16-bit (commonly used in ABB analog input modules)
• Accuracy: ±0.4% of full scale
• Isolation: Galvanic isolation between channels and power supply
• Power Supply: 24 VDC
• Mounting: DIN rail
• Operating Temperature: Typically ranges from -20°C to +60°C (confirm based on specific application)

Technical Specifications:

Product Dimensions & Weight:

• Length: 360 mm
• Height: 10 mm
• Width: 255 mm
• Weight: 0.45 kg

Environmental Information:

• WEEE Category: Small Equipment (External dimensions ≤ 50 cm)
• Exempt from RoHS: Yes (as per EU Directive 2011/65/EU Article 2(4)(c),(e),(f),(j))

Application:

The ABB DSAI110 57120001-DP is purpose-built for use in industrial control systems, particularly within the ABB Advant Master Process Control System. This module is ideal for environments where reliable and accurate analog signal acquisition across multiple input types is critical.
