ABB Bailey NTAI04 – RTD Analog Input Termination Unit

The ABB Bailey NTAI04 terminates resistance temperature detector signals for process control systems. This termination unit measures 165 mm in width and 105 mm in height. It weighs approximately 0.48 kg, so handling remains easy during installation. You will find eight independent input channels on this termination board.

Internal Architecture and Component Layout

This termination unit contains two separate printed circuit boards inside its housing. One board handles signal conditioning, while the other provides electrical isolation. The ABB Bailey NTAI04 includes precision resistors for each of its eight channels. These resistors create a stable voltage divider for accurate temperature readings. The unit stores no energy internally, so it cannot cause unexpected discharges.

Input Compatibility and Wiring Interface

You can connect three-wire or four-wire RTDs to any channel on this device. Each channel accepts platinum RTDs with a 100 ohm nominal resistance. The termination unit also supports copper and nickel RTD types with proper configuration. You will find thirty-two screw terminals on the front panel for field wiring. Each terminal accepts wire gauges from 22 AWG down to 16 AWG.

Signal Processing and Output Connection

The ABB Bailey NTAI04 filters each input signal using a passive low-pass filter circuit. This filter removes high-frequency noise from industrial environments effectively. The termination unit then passes clean signals to a companion analog input module. A 40-pin ribbon cable carries these conditioned signals to the main processor. Each channel provides a measurement resolution of 0.1 degrees Celsius.

Environmental Specifications and Mounting

You can mount this termination unit on any standard DIN rail inside a cabinet. The device operates reliably from 0°C to 60°C ambient temperature. It tolerates humidity levels up to 90 percent without any condensation issues. The ABB Bailey NTAI04 requires no external power supply for its passive circuits. Therefore, you do not need to allocate any power budget for this unit.

Below is a complete summary of its technical specifications.

The ABB Bailey NTAI04 serves as a direct replacement for older termination panels. You do not need to modify existing field wiring during an upgrade. This unit also works seamlessly with Bailey analog input modules like the NTAI05. Consequently, you can expand your temperature monitoring capacity without changing your control strategy.
